Topology Tailoring Method of TWB Autobody Parts Based on HyperWorks

Abstract:

In the paper, a lightweight design method for tailor-welded blanks (TWBs), termed as Topology Tailoring Method (TTM), is proposed, which is based on topology optimization philosophy and in which the variable density method is employed so as to reach the goal of the smallest structure strain energy. By using this method, a TWB autodoor subjected to a specific working condition is topologically optimized in HyperWorks, thus obtaining the more lightweight autodoor. At last, a side impact simulation of the autodoor is demonstrated, thus showing the effectiveness of the method.

• Periodical: Materials Science Forum (Volumes 697-698)
• Pages: 631-635
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.697-698.631
• Online since: September 2011
• Authors: An Ping Xu, Y.S. Liu, H. Wang, Y. Liu, Y.N. Fu
• Keywords: Autobody, Light Weight, Side Impact, Tailor Welded Blanks, Topology Optimization, Topology Tailoring Method

References

[1] S.P. Chen: Automobile Technology & Material Vol. 1 (1995), p.21.

[2] Y.L. Shi, P. Zhu, L.B. Shen: Thin-Walled Structures Vol. 45 (2007), p.8.

[3] Y.L. Shi: Ph.D. Dissertation, Shanghai Jiao Tong University, Shanghai, China, (2008).

[4] P. Zhu, Y.L. Shi, and K.Z. Zhang: IMechE Vol. 222, Part D: Automobile Engineering (2008), p.1337.

[5] F.I. Saunders: Ph.D. Dissertation, Ohio State University, USA, (1994).

[6] Y.L. Mei: Ph.D. Dissertation, Dalian University of Technology, Dalian, China, (2003).

[7] C.Y. Mu: Master's Thesis, Hehai University, Nanjing, China, (2006).
