Crashworthiness Analysis of Mobile Hard Disk under Different Drop Angles

Abstract:

Mobile hard disk is very sensitive to vibration because of unique mechanical working and the complexity of components. In view of inner structure and complying with quality equivalent principle, a 2.5 inch mobile hard disk finite element model is established based on ANSYS/LS-DYNA. The crashworthiness evaluate index is analyzed and set forward. The influence of drop angle is analyzed through simulation. In theoretically, the results are proven to be fundamental method of crashworthiness analysis, evaluation and design for mobile hard disk.

• Periodical: Materials Science Forum (Volumes 697-698)
• Pages: 681-685
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.697-698.681
• Online since: September 2011
• Authors: Shu Yi Yang, D.S. Liu, Ji Yun Zhao, H. Li
• Keywords: Crashworthiness, Drop Angle, LS-DYNA, Mobile Hard Disk

References

[1] J.R. Edwards: IEEE Transactions on Magnetics Vol. 35 (1999), p.864.

[2] E.M. Jayson, Murphy and P.W. Smith: Tribology International Vol. 36 (2003), p.311.

[3] Z. Sheng, R.M. Lin: IEEE Transactions on Magnetics Vol. 37 (2001), p.1146.

[4] D.C. Lin, H.J. Shi and D.B. Zeng: Explosion and Shock Waves Vol. 24 (2004), p.122 (in Chinese).

[5] D.W. Shu, B.J. Shi and H. Meng: Impact Engineering Vol. 34 (2007), p.254.

[6] D.W. Shu, B.J. Shi and H. Meng: Materials Science and Engineering Vol. 423 (2006), p.199.

[7] B.J. Shi, D.W. Shu and S. Wang: International Journal of Impact Engineering Vol. 34 (2007), p.120.
