Investigation on Nozzle Layout at Secondary Cooling Zone of Round Billet Continuous Casting

Abstract:

Nozzle layout has an important role in fulfilling the operational and production requirements. The nozzle arrangements in Ⅱ zone of secondary cooling of a round billet continuous caster in a steel plant are simulated and the water flow density distribution at different range of air pressure and water pressure are analyzed. The result is, the spray zone of two adjacent nozzles which are mutual vertical to each other exist great wrap area，which cannot be eliminated when the air pressure and water pressure are decreased. According to solidification and heat transfer theory, with the steel performance parameter and the accurate boundary conditions, two dimensional heating transfer mathematical model was established, which based on finite difference method and the mind of setting slices on the slab along the casting direction. The surface temperature distribution of round billets in Ⅱ zone of secondary cooling are computed and the temperature curve of different stagger angles of nozzle pairs in consecutive rows are compared. The results show that the temperature at the center of nozzle and spray wrap are all located at the wave trough of surface circumferential temperature curve, the temperature fluctuation of temperature curve that the stagger angle is 22.5° is smaller than when it is 45°. Eliminate the effects of non-uniform surface temperature distribution on the strand quality, thus reducing the defects in the finished product.

• Periodical: Materials Science Forum (Volumes 704-705)
• Pages: 1356-1362
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.704-705.1356
• Online since: December 2011
• Authors: Yan Yan Bi, Deng Fu Chen, Jian Zhang, Shui Gen Wang
• Keywords: Nozzle Layout, Round Billet, Secondary Cooling, Temperature Distribution

References

[1] R. Boyle, J. Frick: Metallurgia Italiana, Vol. 1 (2005), P. 49-52.

[2] X. Jin, D. F. Chen, Q. X. Wang, J. Zhang: The Chinese Journal of Process Engineering, Vol. 8 (2008), P. 161-165.

[3] F. R. Canisani-Calzolari, I. K. Craiq, P. C. Pistorius: ISIJ Int., Vol. 38 (1998), P. 447-453.

[4] G. H. Wen, P. Tang: Iron and Steel, Vol. 5 (1998), P. 49-52.

[5] Q. Liu, L. Z. Wang, L. G. Cao. Journal of Iron and Steel Research, Vol. 17 (2005), P. 6-9.

[6] D. F. Chen, K. Feng, C. S. Xu, H. F. Sun: Metallurgical energy, Vol. 21 (2002), P. 5-8.

[7] P. Guo: Xian Architecture Science and Technology University Master's degree paper, (2001).

[8] K. N. Vdovin: SV Gorostkin-Steel in Translation, Vol. 26 (2000), P. 28-30.

[9] F. R. Camisani-Calzari, I. K. Craig, P. C. Pistorius: IEEE (1999). P. 435-440.

[10] J. H. Guo, X. Hong: Communications in Nonlinear Science & Numerical Simulation, Vol. 4 (1999), P. 236-239.

[11] H. Y. Zhang, X. D. Wang, L. L. Guo: Journal of Iron and Steel Research, Vol. 15 (2008), P. 25-29.

[12] V. D. Fachinotti, A. Cardona: Journal of Materials Processing Technology, Vol. 135 (2003), P. 30-43.

[13] L. L. Guo, X. D. Wang, H. Y. Zhan: ISIJ Int., Vol. 47 (2007), P. 1108–1116.
