Numerical Simulation of Molten Metal Droplet Impinging in Uniform Droplet Spray Rapid Prototyping

Abstract:

A two-dimensional mathematical model has been developed to simulate the impinging and solidification process of a single droplet onto substrate in uniform droplet spray rapid prototyping. Droplet free surface is tracked by volume-of-fluid (VOF) algorithm. The effect of surface tension on the droplet is taken into consideration by means of considering surface tension to be a component of the body force. The governing equations are solved using a finite volume formulation. The calculation results predicted the final shape of a molten droplet impacting onto a solid substrate, and revealed that the solidification process began at the leading edge with the spread process of droplet. The simulation results provide insight and information not easy available from experimental. Keywords: numerical simulation, droplet, rapid prototyping

• Periodical: Materials Science Forum (Volumes 704-705)
• Pages: 680-684
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.704-705.680
• Online since: December 2011
• Authors: Feng Liang Yin, Sheng Zhu, Jian Liu, Yuan Yuan Liang
• Keywords: Droplet, Numerical Simulation, Rapid Prototyping (RP)

References

[1] Ming Fang: Rapid prototyping by deposition of molten metal droplets, University of Toronto, Master thesis, Toronto, Canada, (2003).

[2] L. J. Zarzalejo, K. S. Schmaltz, C. H. Amon: Heat Mass Transfer. Vol. 34 (1999), p.477.

[3] H. Liu, E. J. Lavernia, R. H. Rangel: J. Therm. Spray Technol. Vol. 2 (1993), p.369.

[4] C. W. Hirt, B. D. Nichols: Journal of Computational Physics Vol. 39 (1981), p.201.

[5] R. Ghafouri-Azar, S. Shakeri, S. Chandra et al: Int. J. Heat Mass Transfer Vol. 46 (2003), p.1395.

[6] J. U. Brackbill, D. B. Kothe, C. Zemach: Journal of Computational Physics Vol. 100 (1992), p.335.

[7] Y. Wang, H. L. Tsai: Int. J. Heat Mass Transfer Vol. 44 (2001), p. (2067).
