Finite Element Analysis of Transient Welding Stress and Strain during Ti-6Al-4V Thin Plate Welding with Impact Rotation

Abstract:

The internal thermal transient stress and strain is difficult to be real time measured by experimental methods during welding, but the stress and strain is vital to understand the mechanism of the control on the wave-like deformation. Large nonlinear finite element software of MSC.Mrac is used to illustrate decrease of the wave-like deformation of the Ti-6Al-4V thin plate weldment by a new technique called welding with impacting rotation. Some simulation results such as temperature field, thermal transient stress evolution, elastic strain, plastic strain and distortion of thin plate are shown. By the help of the finite element analysis, the mechanism of control on the wave-like deformation was put forward, i.e. the residual stress was decreased by the certain amount plastic extensive deformation generated by the impacting revolution. Keywords: finite element analysis (FEA), Ti-6Al-4V, thin plate weldment, wave-like deformation, residual stress

• Periodical: Materials Science Forum (Volumes 704-705)
• Pages: 739-744
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.704-705.739
• Online since: December 2011
• Authors: Yong Zhang, Jian Guo Yang, Xue Song Liu, Hong Yuan Fang
• Keywords: Finite Element Analysis (FEA), Residual Stress, Thin Plate Weldment, Ti6Al4V, Wave-Like Deformation

References

[1] M. Watanabe, K. Satoh: Journal of the Japan Welding Society Vol. 27 (1958), p.313–320.

[2] T. Nomoto, T. Terasaki and K. Maeda: Transactions of the Japan Society of Mechanical Engineers A Vol. 63 (1997), p.1063–1068.

[3] T. Terasaki, K. Maeda, H. Murakawa and T. Nomoto: Transactions of the Japan Society of Mechanical Engineers A Vol. 64 (1998), p.2239–2244.

[4] X.M. Zhong, H. Murakawa and Y. Ueda: Transactions of JWRI Vol. 24 (1995), p.199–203.

[5] C.L. Tsai, M.S. Han and G.H. Jung: welding journal Vol. 85(2006), p. 151s–162s.

[6] S.R. Bhide, P. Michaleris, M. Posada and J. Deloach: welding journal Vol. 85(2006), p 189s–194s.
