Modelling the Flow Behaviour of Dual-Phase Steels with Different Martensite Volume Fractions by Finite Element Method

Abstract:

Dual-phase (DP) steels have a composite-type microstructure consisting mainly of hard martensite islands embedded in a soft ferrite matrix. DP steels exhibit a characteristic combination of high strength, high work hardening rate and good ductility. Mechanical behaviour of DP steels is closely related to their microstructures. Hence, it is necessary to take into account their microstructural parameters in any attempt to estimate their flow behaviour. In this study, the flow curves of low carbon DP steels with 26.4 and 52% martensite produced by intercritical annealing processes at different temperatures were calculated using the finite element method (FEM). According to the results of microscopical observations of steel microstructures, martensite islands were assumed in the model to be spherical in shape. Moreover, in agreement with the experimental results in the literature clearly showing the possibility of martensite plastic deformation in similar steels during straining when its volume fraction is greater than about 30%, the plasticity of martensite islands in the steel microstructures was taken into account in the model by using their experimentally obtained stress-strain relations as a function of their estimated carbon contents. Having estimated the stress-strain behaviour of the ferrite phase in all steel samples using the microstructural parameters corresponding to the starting ferrite+pearlite steel, the flow curves of different DP steel samples with elastic martensite (in low martensite content steels) and elasto-plastic martensite (in high martensite content samples) were calculated. The calculated stress-strain curves exhibited reasonable agreements with the experimental stress-strain curves obtained from the tensile tests.

• Periodical: Materials Science Forum (Volumes 706-709)
• Pages: 1503-1508
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.706-709.1503
• Online since: January 2012
• Authors: M. Marvi-Mashhadi, A. Rezaee-Bazzaz, Mohammad Mazinani
• Keywords: Dual Phase Steel, Finite Element Method (FEM), Flow Curve, Martensite Plasticity, Tensile Test

References

[1] F.M. Al-Abbasi, J.A. Nemes, Micro mechanical modeling of dual phase steel, Int. J. Mech. Sci, 2003, Vol. 45, pp.1449-1465.

[2] F.M. Al-abbasi, J.A. Nemes, Micro mechanical modeling of the effect of particle size difference in dual phase steel, Int. J. Solid. Struct, 2003, Vol. 40, pp.3379-3391.

DOI: 10.1016/s0020-7683(03)00156-2

[3] M. Mazinani, W.J. Poole, Effect of martensite plasticity on the deformation behavior of low carbon dual phase steel, Metall. Mater. Trans, 2007, Vol. 38A, pp.328-339.

DOI: 10.1007/s11661-006-9023-3

[4] T. Gladman, I.D. Mc Iover, F.B. Pickering, , J. Iron. Steel. Inst, 1972, Vol. 210, p.910.

[5] Y. Tomato, T. Ohnuki, M. Umemoto, Prediction of tensile properties of hot-rolled steels using micromechanics approach, Proc. 15th Riso Int. Symp. On Mat. Sci, Roskilde, 1994, pp.595-600.

[6] T. Huper, S. Endo, N. Ishikawa, K. Osawa, Effect of volume fraction of constituent phases on the stress-strain relationship of dual phase steels, ISIJ. Int., 1999, Vol. 30, pp.288-294.

DOI: 10.2355/isijinternational.39.288

[7] M. Mazinani, PhD thesis, The university of British Columbia, Van couver, BC, (2006).

[8] T. Gladman, I.D. McIvor, F.B. Pickering, J. Iron Steel Inst., 1972, pp.916-930.

[9] T. Christman, A. Needleman, S. Suresh, An experimental and numerical study of deformation in metal-ceramic composites, Acta Metall, 1989, Vol. 37, pp.3029-3050.

DOI: 10.1016/0001-6160(89)90339-8

[10] P. Poza, J. Lloreca, Mechanical behavior of Al-Li/SiC composites: part III micromechanical modeling, Metall Mater Trans, 1999, Vol. 30A, pp.869-878.

DOI: 10.1007/s11661-999-1020-x

[11] ABAQUS 6. 7. Theory manual. (Hibbit, Karlson & Sorensen. Inc).

[12] H.P. Shen, T.C. Lei, J.Z. Liu, Microscopic deformation behavior of martensitic-ferritic dual phase steels, Mater. Sci. Technol, 1986, Vol. 2, pp.28-33.

DOI: 10.1179/mst.1986.2.1.28

[13] M.S. Rashid, E.R. Cpreck, Relationship between microstructure and formability in two high-strength, low alloy steels, Formability topics-matallic materials, ASTM, STP 647, Philadelphia, PA, American society for testing materials, 1978, pp.174-190.

DOI: 10.1520/stp30052s
