Evaluation of Ultrasonic Waveform for Flaw-Image Reconstruction Using EMAT Probe

Abstract:

Equations for reconstructing 3D images of internal flaws are presented. Waveforms were measured from a simple reference sample to derive the response function of the probe, and the response function was calculated based on those waveforms. A sample with internal flaws was prepared to evaluate the reconstructed images of internal flaws derived by EMAT using magnetostrictives. 3D-images of an internal flaw could be derived using this response function.

• Periodical: Materials Science Forum (Volume 721)
• Pages: 243-248
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.721.243
• Online since: June 2012
• Authors: Yoshihiro Nishimura, Takayuki Suzuki
• Keywords: Barkhausen Effect, EMAT, Magnetostrictive, Response Function, UT

References

[1] S. Nagata, H.Kai and M. Enokizono: Material Science Forum Vol.670(2011), pp.151-157.

[2] Y. Nishimura, A. Sasamoto and T. Suzuki: Proc. of JAPMED6 (2009) , pp.119-120.

[3] Y. Nishimura, A. Sasamoto and T. Suzuki: Material Science Forum Vol. 670(2011), pp.345-354.

[4] Y.Nishimura and T.Suzuki: Pro. of JAPMED7 (2011), pp.117-118.

[5] D.Braconier: Proc. of JSNDI (2006), pp.35-36

[6] K. Nakahata, M. Hirata and S. Hirose: J. of JSNDI, Vol.59-6 (2010), pp.277-283.

[7] Y.Nishimura, A.Sasamoto and T.Suzuki: Int. J of Applied Electromagnetics and Mechanics, Vol. 28-1 (2008), pp.171-176.

[8] A.N. Tikhonov, V.Y. Arsenin, Solution of ill-posed Problems, Winston \& Sons, Washington, D.C., 1977.
