A 3D Cohesive Element Model for Fracture Behavior Analysis of Ceramic Tool Materials Microstructure

Abstract:

A 3D finite element polycrystalline microstructure model of ceramic tool materials is presented. Quasi-static crack propagation is modeled using the cohesive finite element method (CFEM) and the microstructure is represented by 3D Voronoi tessellation. The influences of cohesive parameters, the ratios of maximum traction of grain boundary to maximum traction of grain on the crack patterns of Al2O3 have been discussed. This study has demonstrated the capability of modeling 3D crack propagation of ceramic microstructure with CFEM and Voronoi tessellation model. It is found that the fracture mode is changed from intergranular to transgranular as the maximum traction of grain boundary is increased.
