Design and Dynamic Analysis of Micro Milling Machine

Abstract:

In this paper, methods of micro-fabrication carried out by micro milling machine are proposed. Structure design and simulation analysis of micro milling machine are accomplished. A 3D parametric modeling software CATIA is used to complete the structure design and modeling of micro milling machine and a simulation software ANSYS is used to do the whole analysis of micro milling machine. The static and dynamic simulation analysis of motorized spindle which is the key part of micro milling machine is also completed. Through simulation and analysis to seek the rationality of the design of micro milling machine. It has important significance for the improvement and development of machine tool in the next step.

• Periodical: Materials Science Forum (Volume 723)
• Pages: 412-418
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.723.412
• Online since: June 2012
• Authors: Xiao Zhou Li, Jian Dong Yang, Li Meng Wang, Qiu Han Ma, Feng Qiu
• Keywords: Micro Parts, Micro-Milling Machine, Modal Analysis, Structure Design

References

[1] J. Chae, S. Park and T. Freiheit: Int J Mach Tools Manuf. 46 (2006) 313-332.

[2] G.M. Robinson, M.F. Jackson: J Mater Process Technol. 167 (2005) 316-333.

[3] G.M. Robinson, M.J. Jackson: J Mater Process Technol. 167(2/3) (2005) 316-337.

[4] X.C. Luo, K. Cheng, W. Dave: J Mater Process Technol. 167(2/3) (2005) 515-528.

[5] T. Kitaharat, Y. Ishikawa: J Mech Eng Lab. 50(5) (1996) 117-123.

[6] Z.N. Lu, T. Yoneyama: Int J Mach Tools Manuf. 39(7) (1999) 1171-1183.

[7] B. Bern, F. Jay. A. Tu: Int J Mach Tools Manuf. 39 (1999) 1345-1366.

[8] K. Sun-min, L. Kang-jae, L. Sun-kyu: Int J Mach Tools Manuf. 42 (2002) 365-373.

[9] K. Sun-min, L. Sun-kyu: Int J Mach Tools Manuf. 41 (2002) 809-831.
