Study of Measurement Methods of Particle Velocity in a Spouted Bed

Abstract:

Average particle velocity measurements were carried out in a conical-cylindrical spouted bed made of acrylic. In this study an intrusive fiber optical technique which is based on a cross-correlation function between signals from its two channels was used. For a non-intrusive measurement in order to compare with the intrusive technique, images of particle movement were recorded using a high-speed video camera. The experiments were conducted in differents air velocity conditions above the minimum spouting velocity. The latter method was limited in velocity measurement only near the spouted beds wall inasmuch as the spouted bed used was a three dimensions one. On the other hand, the fiber optical is a promising technique for measuring particle velocity distributions in a three dimensions spouted bed. To predict the minimum spouting velocity in order to use this result in the measurement techniques investigation, simulations were carried out using the Eulerian-Eulerian multiphase model.

• Periodical: Materials Science Forum (Volumes 727-728)
• Pages: 1842-1847
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.727-728.1842
• Online since: August 2012
• Authors: D.A. Santos, G.C. Alves, M.A.S. Barrozo, Claudio Roberto Duarte
• Keywords: Computational Fluid Dynamics (CFD), Measurement Technique, Particle Velocity, Spouted Bed

References

[1] M. Olazar, R. Aguado, M. J. San Jose and J. Bilbao: Recents Progres en Genie des Procedes Vol. 14 (2000), p.499.

[2] R.S. Conceição Filho, M.A.S. Barrozo, J.R. Limaverde and C.H. Ataíde: Drying Technology Vol. 16 (1998), p. (2049).

DOI: 10.1080/07373939808917511

[3] C.R. Duarte, J.L.V. Neto, M.H. Lisboa, R.C. Santana, M.A.S. Barrozo and V.V. Murata: Brazilian Journal of Chemical Engineering Vol. 21 (2004), p.59.

[4] C.R. Duarte, V.V. Murata and M.A.S. Barrozo: Canadian Journal of Chemical Engineering Vol. 82 (2004), p.116.

[5] F.G. Cunha, K.G. Santos, C.H. Ataíde, N. Epstein and M.A.S. Barrozo: Industrial & Engineering Chemistry Research Vol. 48 (2009), p.976.

[6] J.L. Vieira Neto, C.R. Duarte, V.V. Murata and M.A.S. Barrozo: Drying Technology Vol. 26 (2008), p.299.

[7] K.B. Mathur and N. Epstein: Spouted Beds (Academic Press Inc. LTD., New York, 1974).

[8] D.O. Silva, L.M. Tamiozo, C.R. Duarte, V.V. Murata and M.A.S. Barrozo: Drying Technology Vol. 29 (2011), p.286.

[9] K. G. Santos, V.V. Murata and M.A.S. Barrozo: Canadian Journal of Chemical Engineering Vol. 87 (2009), pp.211-219.

[10] D.A. Santos, I. Petri Jr, M.A.S. Barrozo and C.R. Duarte: Material Science Forum Vols. 660-661 (2010), p.448.

[11] C.R. Duarte, V.V. Murata and M.A.S. Barrozo: Powder Technology Vol. 188 (2009), p.195.

[12] C.R. Duarte, V.V. Murata and M.A.S. Barrozo: Brazilian Journal of Chemical Engineering Vol. 22 (2005), p.263.

[13] T. Kawaguchi, M. Sakamoto, T. Tanaka, Y. Tsuji: Powder Technology, Vol. 109(2000), pp.3-12.

[14] E.U. Hartge, Y. Li, J. Werther: Fluidization V (1986), p.345.

[15] J.M. López-Higuera, Handbook of optical fibre sensing technology. John Wiley & Sons Ltd, Chichester, England (2002).

[16] M.J. San José, M. Olazar, S. Alvarez, A. Moralez and J. Bilbao: Chemical Engineering Science Vol. 60(2005), p. (2017).

[17] Y.L. He, C.J. Lim, J.R. Grace, J.X. Zhu and S.Z. Qin: Canadian Journal of Chemical Engineering Vol. 72 (1994), p.229.

[18] M.A.S. Barrozo, C.R. Duarte, N. Epstein, J.R. Grace and C.J. Lim: Industrial & Engineering Chemistry Research Vol. 49 (2010), p.5102.

[19] W. Du, X. Bao, J. Xu and W. Wei: Chemical Engineering Science Vol. 61 (2006), p.4558.

[20] J. -X. Zhu, G. -Z. Li, S. -Z. Qin, F. -Y. Li, H. Zhang and Y. -L. Yang: Powder Technology Vol. 115(2001), p.184.
