Laser Cutting of Small Diameter Nitinol Tube

Abstract:

In this article the complex research and development project of the laser cutting micromachining of nitinol alloys are shown. The laser cutting parameters of the 1.04 mm inner diameter and 0.1 mm wall thickness nitinol tubes are also shown. The laser cutting parameters of micromachining and the cut surface of nitinol tubes are summarized when 3 mJ pulse energy, 0.02 ms pulse duration, 6 bar Ar gas pressure, 3000 Hz frequency, 10 mm/s rotation speed and 5 mm/s² speed-up were used. The effect of the laser cutting to the raw material is characterized by microstructural and micromechanical examinations. A detailed description is given of the energy input by laser beam machining. The pulse and the impact of the applied pressure parameters of the gas to the raw material are also shown.

• Periodical: Materials Science Forum (Volume 729)
• Pages: 460-463
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.729.460
• Online since: November 2012
• Authors: Péter Nagy, János Dobránszky
• Keywords: Laser Cutting, Micro Machining, Nitinol, Stent

References

[1] D. Domján, L.M. Molnár, E. Bognár, T. Balázs: Development of Polymer Coatings for Coronary Stents. MATERIALS SCIENCE FORUM (ISSN: 0255-5476) 659 (2010) 141-146.

DOI: 10.4028/www.scientific.net/msf.659.141

[2] B. Robák, P. Szabadíts, E. Bognár, A. Toldy, Zs. Puskás: Analysis of the polymer coatings of coronary stents from the aspect of drug absorbing and eluting. MATERIALS SCIENCE FORUM (ISSN: 0255-5476) 659 (2010) 245-250.

DOI: 10.4028/www.scientific.net/msf.659.245

[3] D. Stoeckel, A. Pelton, T. Duerig: Self-Expanding Nitinol Stents -Material and Design Considerations, Nitinol Devices & Components Johnson & Johnson company (2003) 1-13.

DOI: 10.1007/s00330-003-2022-5

[4] P. Poncin, A. Loshakove, D.A. Capp: Laser cutting Nitinol tubes. SMST-2003: Proceedings of the International Conference on Shape Memory and Superelastic Technologies. A.R. Pelton, T. Duerig (ed. ), DOI: 10. 1361/cp2003smst239 (2004) 239-246.

[5] R. Pfeifer, D. Herzog, M. Hustedt, S. Barcikowski: Pulsed Nd: YAG laser cutting of NiTi shape memory alloys—Influence of process parameters, Journal of Materials Processing Technology 210 (2010) 1918–(1925).

DOI: 10.1016/j.jmatprotec.2010.07.004

[6] M. I. Khan, S. K. Panda, Y. Zhou: Effects of Welding Parameters on the Mechanical Performance of Laser Welded Nitinol, Materials Transactions, Vol. 49, No. 11 (2008) 2702 to 2708.

DOI: 10.2320/matertrans.mra2008243

[7] M.I. Khan, Y. Zhou: Effects of local phase conversion on the tensile loading of pulsed Nd: YAG laser processed Nitinol, Materials Science and Engineering A 527 (2010) 6235–6238.

DOI: 10.1016/j.msea.2010.06.025

[8] Y.P. Kathuria: Laser microprocessing of metallic stent for medical therapy, Journal of Materials Processing Technology 170 (2005) 545–550.

DOI: 10.1016/j.jmatprotec.2005.05.041
