Mechanical Properties of AlMgB_14-xTiB₂ Prepared by Field Activated and Pressure Assisted Synthesis

Abstract:

In this paper, Mechanical alloying (MA) and field activated and pressure assisted synthesis (FAPAS) were used for preparing the ultra-hard, super-abrasive AlMgB₁₄-xTiB₂ composite ceramic. The samples were fabricated at 1500 under a pressure of 60 MPa. The microstructures and compositions of samples were observed and determined by scanning electron microscopy (SEM), energy dispersive X-ray analysis (EDX), X-ray diffraction (XRD). It was indicated that addition of TiB₂ was effective for increasing both quantities. A maximum Vichers hardness of 38.5GPa and a fracture toughness of 3.85MPam^½ of AlMgB₁₄ reinforced with 70 wt.% of TiB₂ were achieved. Abrasion wear tests showed that adding TiB₂ would improve the wearability obviously.

You might also be interested in these eBooks

Advances in Functional and Electronic Materials

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 745-746)

Pages:

652-656

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.745-746.652

Citation:

Cite this paper

Online since:

February 2013

Authors:

Yang Miao, Wen Liu, Lei Zhuang, Hui Ling Cheng, Qing Sen Meng

Keywords:

AlMgB_14-xTiB₂, FAPAS, Mechanical Property, Ultra-Hard Boride

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] J.S. Peters, B.A. Cook, J.L. Harringa, A.M. Russell, Microstructure and wear resistance of low temperature hot pressed TiB2, Wear. 266 (2009) 1171-1177.

DOI: 10.1016/j.wear.2009.03.027

Google Scholar

[2] J. David, Roberts, Jinfeng Zhao, et al. Mechanism of reactive sintering of MgAlB14 by pulse electric current, Journal of Refractory Metals & Hard Materials. 27 (2009) 556-563.

DOI: 10.1016/j.ijrmhm.2008.07.009

Google Scholar

[3] T.L. Lewis, B.A. Cook, J.L. Harringa, A.M. Russell, Al2MgO4, Fe3O4, and FeB impurities in AlMgB14, Materials Science and Engineering. 351 (2003) 117-122.

DOI: 10.1016/s0921-5093(02)00835-3

Google Scholar

[4] B.A. Cook, J.S. Peters, J.L. Harringa, A.M. Russell, Enhanced wear resistance in AlMgB14–TiB2 composites, Wear. 271 (2011) 640-646.

DOI: 10.1016/j.wear.2010.11.013

Google Scholar

[5] A. Ahmed, S. Bahadur, A.M. Russell, B.A. Cook, Belt abrasion resistance and cutting tool studies on new ultra-hard boride materials, Tribology International. 42 (2009) 706-713.

DOI: 10.1016/j.triboint.2008.10.013

Google Scholar

[6] R.X. Chen, Q.S. Meng, W.H. Fan, et al. Effect of Electric Current on the Performance of Bi1. 2Sb4. 8Te9 Thermoelectric Material Prepared by a Field-activated and Pressure-assisted Sintering Process, Journal of electronic materials. 40 (2011).

DOI: 10.1007/s11664-011-1563-7

Google Scholar

[7] A. Ahmeda, S. Bahadura, B.A. Cook, J. Peters, Mechanical properties and scratch test studies of new ultra-hard AlMgB14 modified by TiB2, Tribology International. 39 (2006) 129-137.

DOI: 10.1016/j.triboint.2005.04.012

Google Scholar
