In-Depth Distribution of Stresses Measured by Multireflection Grazing Incidence Diffraction

Abstract:

The geometry based on the multireflection grazing incidence X-ray diffraction (called the MGIXD method) can be applied to measure residual stresses. Using this method, it is possible to perform a non-destructive analysis of the heterogeneous stresses for different and well defined volumes below the surface of the sample (range of several mm). As the result the average values of stresses weighted by absorption of X-ray radiation are measured. In this work the stress profile as a function of depth for mechanically polished Ti and Al samples were calculated from MGIXD data using inverse Laplace transform.

• Periodical: Materials Science Forum (Volume 772)
• Pages: 143-147
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.772.143
• Online since: November 2013
• Authors: Marianna Marciszko, Andrzej Stanisławczyk, Andrzej Baczmanski, Krzysztof Wierzbanowski, Wilfrid Seiler, Chedly Braham, Mirosław Wróbel, Barbara Szaraniec
• Keywords: Elastic Constants, Grazing Incidence Diffraction, Residual Stress

References

[1] U. Welzel, J. Ligot, P. Lamparter, A. C. Vermeulenb and E. J. Mittemeijer, (2005). J. Appl. Cryst. 38, 1–29.

[2] Ch. Genzel (1994). Phys. Status Solidi A, 146, 629–637.

[3] A. Kumar, U. Welzel and E. J. Mittemeijer, J. Appl. Cryst. (2006). 39, 633–646.

[4] J. Bonarski, J. Smolik J., L. Tarkowski, M. Biel, (2008). Arch. Metall. and Mater., 53, 49-55.

[5] S.J. Skrzypek, A. Baczmanski, (2001). Adv. X-ray Anal. 44, 134–145.

[6] S.J. Skrzypek, A. Baczmanski, W. Ratuszek, E. Kusior, (2001). J. Appl. Cryst. 34, 427–435.

[7] A. Baczmański, C. Braham, W. Seiler and N. Shiraki, Surface and Coating Technology, (2004). 182, 43-54.

[8] S. Wroński, K. Wierzbanowski and A. Baczmański, Powder Diffraction Suppl. 24 (2009) S11-S15.

[9] T. Erbachen, A. Wanner, T. Beck and O. Vohringer, (2007). J. Appl. Cryst. 41, 317-385.
