Forming Parameter Design and Thickness Uniformity Control of Short Radius Elbow Made by Expanding Diameter and Pushing Bend

Abstract:

The forming theory of elbow made by expanding diameter and pushing bend is introduced in this paper. The tube blank of elbow takes place combined deformation with compression deformation in the axial direction and in the circumferential direction. The compression deformation in the axial direction makes tube bending deformation under the restricted condition of ram-shape die, then the belly metal of elbow thicken after compression deformation, while the back metal of elbow don’t take part in deformation. The eccentric expanding diameter in the circumference direction ensures the thickened wall thickness flowing favorably from elbow belly to elbow back and supplying the reduced wall thickness of back elbow. Comparatively, the compression deformation and expanding diameter deformation of short radius elbow is larger than that of long radius elbow. According to metal flowing law, proper ram-shape die design and pushing rate, increasing heating temperature, improving temperature field distribution and lubrication condition can assure uniformity wall thickness.

• Periodical: Materials Science Forum (Volume 788)
• Pages: 150-157
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.788.150
• Online since: April 2014
• Authors: Jun Chen*, Ying Li Yang, Hai Ying Yang, Ting Xun Wang
• Keywords: Expanding-Diameter, Pushing Bend Procedure, Ram-Shaping Deformation Die, Short Bending Radius

References

[1] Duan Wensen et al: 1st Symposia Proceedings of Chinese pipeline academic, Hefei: 1997: 79-83

[2] Chen Jun, Yang Haiying and Duan Wensen: International Conference on Advances in Materials Science and Manufacturing Technology，992-996

[3] Huang Xia, Zeng Yuansong, Zhang Xinhua et al. Aeronautical manufacturing technology, 2005，(10): 74-77，97

[4] Chen Jun, Wang Tingzun, Duan Wensen and Yang Haiying. The forming technology of titanium alloy elbow, Oil tuber goods engineering, 2011，Vol.17(6):1-6

[5] Chen Jun, Duan Wensen and Yang Haiying. 2008，Vol.37(Suppl.4):555-560

[6] Duan Wensen，Chen Jun and Yang Haiying, Oil tuber goods engineering, 2008, 14(1),1～8

[7] Li Kui. Construction technology (Ji Lin) , 1994, (2):32-38

[8] Lu Xiaoyang，Shi Baojun, Lu Xiaoli. Metal forming machinery, 1997, (4):10-13

[9] Mechanics and engineering， Lu Xiaoyang，Xu Bingye, Cen Zhangzhi, Shi Baojun. Mechanics and engineering, 1998, Vol20(6):15-17

[10] Lu Xiaoyang，Xu Bingye, Li Kui. 1994, (7):11-14,25

[11] Chen Jun, Duan Wensen and Yang Haiying, Proceedings of the 12th world conference on titanium, 1114-1118

[12] Duan Wensen. Acta Metallurgica Sinica, 2002, 38(sup.1):422～424
