Investigation of Magnet Arrangements in Double Layer Interior Synchronous Permanent Magnet Motor over Wide-Speed Range for Electric Vehicle Applications

Abstract:

In this paper, the magnet arrangement for a manufactured Double Layer Interior Synchronous Permanent Magnet Motor (DLISPMM) for Electric Vehicle (EV) applications is investigated. In a first step, the manufactured motor is optimized for its nominal condition, by using a particular design of experiment (DOE) method. In a second step, a comparative analysis for the two types of DLISPMMs for a wide speed range operation is performed, by using a parametric Finite Element (FE) model, for calculation of the main machine characteristics, in conjunction with a convenient dynamic model, considering magnetic saturation, for implementation of field weakening control. The initial linear and the final, considering magnetic saturation, dynamic models are evaluated. Finally, the initial and final designs are compared in terms of the main operating characteristics for both nominal low speed and high speed field weakening operation.

• Periodical: Materials Science Forum (Volume 792)
• Pages: 379-384
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.792.379
• Online since: August 2014
• Authors: Athanasios G. Sarigiannidis*, Minos E. Beniakar, Panagiotis E. Kakosimos, Antonios Kladas
• Keywords: Electric Vehicle Applications, Field Weakening Capability, Finite Element, Interior Synchronous Permanent Magnet Motors, Magnetic Saturation, Maximum Torque per Ampere Control

References

[1] A. Muntean et al., Torque Analysis and Control of Double Layer Interior Synchronous Permanent Magnet Motor for Electric Vehicle Propulsion Applications, Electromotion, (2009).

DOI: 10.1109/electromotion.2009.5259127

[2] K. Yamazaki, K. Kitayuguchi, Investigation of Magnet Arrangements in Double Layer Interior Permanent Magnet Motor, ECCE, (2010).

DOI: 10.1109/ecce.2010.5618270

[3] P. E. Kakosimos, A. G. Sarigiannidis, M. E. Beniakar, A.G. Kladas, and C. Gerada, Induction Motors versus Permanent Magnet Actuators for Aerospace Applications, IEEE Trans. Ind. Electron., vol. 61, no. 9, pp.4315-4325, Aug. (2014).

DOI: 10.1109/tie.2013.2274425

[4] M. A. Hoque, C. Butt and M. A. Rahman, A Novel Approach for MTPA Speed Control of IPMSM Drive, 2nd International Conference on Electrical and Computer Engineering, (2002).

[5] Lazi J. M. et al., Performance comparison of SVPWM and Hysteresis Current Control for Dual motor drives, Applied Power Electronics Colloquium (IAPEC), (2011).

DOI: 10.1109/iapec.2011.5779854

[6] Larminie J., Lowry J., Electric Vehicle Technology Explained, John Wiley and Sons, (2003).
