Cutting Edge Mathematical Model for Ellipsoidal End Mill

Abstract:

In this paper, a new kind of ellipsoid end mill is proposed in order to improve the quality and efficiency in machining the sculptured surface. An integral ellipsoid end mill parameter optimization system architecture is developed to make the parametric design automatically and efficiently. Then, the mathematical model of continuous blade curve with constant helix angle and normal helix cutting edge of ellipsoid end mill is presented, as well as the cutting edge on the cylinder of cylindrical ellipsoid end mill. And then, all curves are simulated based on MATLAB software. Finally, the ellipsoid end mill is manufactured using a SAACKE UWIF CNC grinding machine to verify the feasibility of ellipsoid end mill.

• Periodical: Materials Science Forum (Volumes 800-801)
• Pages: 495-500
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.800-801.495
• Online since: July 2014
• Authors: Meng Chao Fan*, Xian Li Liu, Wei Ji, Dian Ge Zuo, Ming Yang Wu
• Keywords: Constant Helix Angle Cutting Edge, Ellipsoid End Mill, Normal Helix Cutting Edge, Tool Design
