Uncertain-but-Nonrandom Dynamic Optimization of Composites Flexible Membrane Structure

Abstract:

In the past few years, owing to the vital role in maritime safety monitoring and marine hazard warning, stratospheric airship has become a research hotspot around the world. The structure of stratospheric airship is a typical aerated flexible membrane one. It is geometrical nonlinear in essence and it bears a distinct mechanical nature of large deformation. Therefore it makes optimizing the structure more difficult. The current studies of air-supported flexible membrane structural optimization ignore the uncertainty influence which is resulted from the loading environments, material properties and structural parameters. According to the Lagrangian Coordinate method, the deformed configuration is used as a reference in order to build accurate strain/displacement geometry. The Equilibrium equation is created by using the principle of virtual work. Meanwhile, the accuracy and stability of the solution is ensured by using the Updated Lagrangian Formulation. The uncertain parameters which are introduced during the analysis and optimization of the aerated flexible membrane structure are portrayed by interval mathematical theory. With respect to engineering application, the factors of uncertainty are considered. Maximizing the structural fundamental frequency (or first-order natural frequency) is taken as the objective, while structural integrity is taken as the constraint. Then the dynamic optimization is carried out under interval uncertainty. In this way the reliability of the membrane structure in complex conditions is improved and the probability of failure is reduced.

• Periodical: Materials Science Forum (Volume 813)
• Pages: 43-53
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.813.43
• Online since: March 2015
• Authors: He Chen Qiu*, Zhi Ping Qiu
• Keywords: Air-Supported Membrane, Dynamic optimization, Large Deformation, Nonlinear, Uncertainty

References

[1] Lv Xiaohong, New trends in world military airship development, Winged Missiles Journal. 7 (2003) 21-23.

[2] Qu Dongcai, Study and development of airship, Aeronautical Science and Technology. 2(2005) 20-23.

[3] Chen Wujun, Dong Shilin, Research and development of airship and high altitude long endurance platform in Germany(Europe), Spatial Structures. 12(2006) 3-7.

[4] Chen Wujun, He Yanli, Large airship initial morphological analysis and study of structural system, Aerostat research. 1(2006) 41-46.

[5] M.A. Rehmet, B.H. Kroplin, Comparison between airship and aircraft, 3rd International Airship Convention and Exhibition in Friedrichshafen(2000).

[6] Cao Xiuyun. Near space vehicle become recent national research hotspot, Aerospace China. 7(2006) 30-32.

[7] Wang Wenjun, Li Yong, Estimation of the relationship between the pressure in airship ballonet and tension in its envelop, Journal of Astronautics. 28(2007) 1109-1112.

[8] Bessert N, Frederich O, Nonlinear Airship Aeroelasticity, Journal of Fluids and Structures. 21(2005) 731-742.

DOI: 10.1016/j.jfluidstructs.2005.09.005

[9] Verron E, Marckmann G, Peseux B, Dynamic Inflation of Nonlinear Elastic and Viscoelastic Rubberlike Membranes, International Journal for Numerical Methods In Engineering. 50(2001) 1233-1251.

DOI: 10.1002/1097-0207(20010220)50:5<1233::aid-nme77>3.0.co;2-w

[10] Li Fanghui, Wei dong, Shen shizhao, Form finding of air-supported membrane structures, Journal of Harbin Institute of Technology. 35(2003) 869-872.

[11] Jiang Xihu, Xie Buying, Non-linear analysis of air-supported membrane model by ANSYS, J. University of Shanghai for Science and Technology. 28(2006) 213-217.

[12] Weng Yanlin, Guan Fuling, The Optimize Design of the Air-supported Membrane Structures, Bulletin of science and technology. 22(2006) 535-548.

[13] Wang Changguo, Mao Lina, Du Xingwen, Influence Parameter Analysis and Wrinkling Control of Space Membrane Structure, International Journal of Mechanics of Advanced Materials and Structures. 17(2010) 49-59.

DOI: 10.1080/15376490903082862

[14] Tan Huifeng，Mao Lina，Wang Changguo, Shape analysis and optimization of inflatable membrane reflector, Advanced Lightweight Structures and Reflector Antennas, Tbilisi, Georgia. (2009) Oct 14th-16th.

[15] Yang Qingshan, Jiang Yinan, Analysis and design of tensioned cable-membrane structures, first ed., Science Press, Beijing, (2004).

[16] Chen Wujun, Design of membrane structure engineering, first ed., China architecture & building Press, Beijing, (2004).

[17] Zhang Jian, Yang Qingshan, Form-state and loading analyses of air-flated cushion membrane structures, Journal of Harbin institute of technology. 40(2008) 2020-(2023).

[18] Liu Changjiang, Zheng ZhouLian, He Xiao-Ting, L-P perturbation solution of nonlinear free vibration of pre-stressed orthotropic membrane in large amplitude, Mathematical Problems in Engineering. 13(2010) 561-578.

DOI: 10.1155/2010/561364

[19] Xu M, Qiu Z, Free vibration analysis and optimization of composite lattice truss core sandwich beams with interval parameters, Compos Struct, 106(2013) 85-95.

DOI: 10.1016/j.compstruct.2013.05.048
