Structure and Properties of W-Ti Thin Films Deposited by Magnetron Sputtering

Abstract:

W-Ti thin films with different Ti contents were prepared by dc magnetron sputtering on silicon substrates of p-type (100) orientation, and the pure W and pure Ti thin films with the same thick were also prepared for comparison. The microstructure and properties of W-Ti thin film were characterized by XRD, SEM, AFM, microhardness tester and four-point probe method. The results show that the thin films exhibited a polycrystalline structure in the form of columnar grains, and only b.c.c. W phase could be registered in the films, and with the increase of Ti content, the solid solution of W-Ti was found. Compared to pure W film, the microhardness of W-Ti films decreased with the increasing of Ti content, while the sheet resistance rises with the increasing of Ti content. The microhardness of W-Ti thin films was higher than pure Ti thin films, and the sheet resistance was lower than pure Ti thin films.

• Periodical: Materials Science Forum (Volume 849)
• Pages: 654-658
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.849.654
• Online since: March 2016
• Authors: Guo Qi Sun, Sun Yong*, Yong Hua Duan
• Keywords: Magnetron Co-Sputtering, Microhardness, Sheet Resistance, W-Ti Thin Films

References

[1] Petrović S, Bundaleski N, Peruško D, et al. Surface analysis of the nanostructured W-Ti thin film deposited on silicon. Appl Surf Sci, 2007, 253(12): 5196—5202.

DOI: 10.1016/j.apsusc.2006.10.077

[2] L.B. Jonsson, C. Hedlund, I.V. Katardjiev, S. Berg, Thin Solid Films 348 (1999) 227.

[3] Oparowski J M, Sisson RD, Biederman R R. Thin Solid Films 1987; 153: 313.

[4] Wang S Q, Suthar S, Hoeflich C, et al. Diffusion barrier properties of TiW between Si and Cu. Appl Surf Sci, 1993, 73(5): 2301—2304.

DOI: 10.1063/1.353135

[5] Wang Yuan, Li Xiaohua, Song Zhongxiao, et al. The structure and residual stress of an-nealed Cu-W thin films [ J] . Rare Metal M ater Eng. 2007, 36( 3) : 435.

[6] Xia Yang, Song Yueqing, Cui Shun , et al., Preparation and properties of Mo-Cu and W-Cu alloys [J] . Chinese J Rare Metals, 2008, 32( 2): 240.

[7] JCPDS—International Centre for Diffraction Data (ICDD), PCPDFWIN v. 2. 00(1998).

[8] ASAMI K, MORIYA T, HASHIMOTO K, et al. Roles of temperature and humidity in the oxidation of sputter-deposited Cu-Ta alloys in air[J]. Corrosion Science, 2002, 44: 331- 344.

DOI: 10.1016/s0010-938x(01)00064-6

[9] Makinoa Y, Moria M, Miyake S. Characterization of Zr-Al-N films synthesized by a magnetron sputtering method. Surf Coat Technol, 2005, 193(1-3): 219—222.

[10] Bhagat S K, Theodore N D, Alford T L. Thermal stability of tungsten-titanium diffusion barriers for silver metallization. Thin Solid Films, 2008, 516(21): 7451—7457.

DOI: 10.1016/j.tsf.2008.03.021

[11] BULL S J, BHAT D G, STAIA M H. Properties and performance of commercial TiCN coatings, part 2: tribological performance[J]. Surface and Coating Technology, 2003, 163-164: 507-514.

DOI: 10.1016/s0257-8972(02)00651-5

[12] LOURO C, CAVALEIRO A. Hardness versus structure in W-Si-N sputtered coatings[J]. Surf Coat Technol, 1999, 116-119(1): 74-80.

DOI: 10.1016/s0257-8972(99)00277-7

[13] Electron Microscopy Image Simulation, http: /cecm. insa-lyon. fr/CIOLS/crystal4. pl.
