Plasma-MIG Hybrid Welding Process of 5083 Marine Aluminum Alloy

Abstract:

Plasma-MIG hybrid welding and MIG welding of 5083 marine aluminum alloy was carried out. The influences of parameters of welding process on the weldments morphology were investigated in order to optimize the welding process parameters. The macrostructure, microstructure, tensile and bending properties of the optimized joint were studied. The results show that Plasma-MIG hybrid welding not only has a synergistic effect of Plasma and MIG welding but also has a high welding efficiency. Welding speed, Plasma current and MIG current have a significant effect on welding penetration and welding morphology. Meanwhile, the ductility and strength property of weld joint was qualified though the bending test and tensile test. The average tensile strength of weld joint is about 285MPa at room temperature, about 86% of the base metal.

• Periodical: Materials Science Forum (Volume 850)
• Pages: 519-525
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.850.519
• Online since: March 2016
• Authors: De Tao Cai*, Shan Guo Han, Shi Da Zheng, De Jun Yan, Jiu Qiang Luo, Xiao Li Liu, Zi Yi Luo
• Keywords: 5083 Aluminum Alloy, Mechanical Properties, Microhardness, Microstructure, Plasma-MIG Hybrid Welding, Weldments Morphology

References

[1] S. J. Lee, S. J. Kim, Effects of flow velocity on electrochemical behavior of seachest 5083-H116 Al alloy for ship, Trans. Nonferrous Met. Soc. China. 8(2011)1703-1709.

DOI: 10.1016/s1003-6326(11)60918-7

[2] Y. Liu, W.J. Wang, et al., Microstructure and mechanical properties of aluminum 5083 weldments by gas tungsten arc and gas metal arc welding, Mater. Sci. Eng. A. 549(2012)7-13.

DOI: 10.1016/j.msea.2012.03.108

[3] B. Hu, I. M. Richardson, Microstructure and mechanical Properties of AA7075(T6) hybrid laser-GMA welds, Mater. Sci. Eng. A, 459 (2007) 94-100.

DOI: 10.1016/j.msea.2006.12.094

[4] P. Prachya, W. Anucha, Influence of Shielding Gas on Aluminum Alloy 5083 in Gas Tungsten Arc Welding, Procedia Engineering, 29(2012)2465 - 2469.

DOI: 10.1016/j.proeng.2012.01.333

[5] D. H. Choi, B. W. Ahn, D. J. Quesnel, S. B. Jung, Behavior of β phase (Al3Mg2) in AA 5083 during friction stir welding, Intermetallics, 35(2013)120-127.

DOI: 10.1016/j.intermet.2012.12.004

[6] W.G. Essers, A.C. Liefkens, Plasma-MIG welding developed by Philips, Machinery and Production Engineering, 121(1972) 631-634.

[7] G. Jelmorini, G. W. Tichelaar, W. G. Essers, et al., Welding Characteristics of the Plasma-MIG Process, Metal Construction, 11 (1975)568-572.

[8] G. Jelmorini,G. W. Tichelaar, W. G. Essers, et al., Welding characteristics of the plasma-MIG process, Metal Construction, 11(1975)568-572.

[9] Ono Kohei, Z. J. Liu, Era Tesuo, Development of a plasma MIG welding system for aluminium, Weld. Int., 23(2009) 805-809.

DOI: 10.1080/09507110902836945

[10] C. H. Kim,Y. N. Ahn, K. B. Lee, Droplet transfer during conventional gas metal arc and plasma-gas metal arc hybrid welding with A1 5183 filler metal, Curr. Appl. Phys., 12(2012)S178-S183.

DOI: 10.1016/j.cap.2012.03.001

[11] Y. Bai, H. M. Gao, L. Qiu, Droplet transition for plasma-MIG welding on aluminium alloys, Trans. Nonferrous Met. Soc. China, 20(2010)2234-2239.

DOI: 10.1016/s1003-6326(10)60634-6

[12] W. G. Essers, G. A. M. Willems, J. J. C. Buelens, M. R. M van Gompel, Plasma-MIG welding-a New torch and arc sarting method, Metal Construction, 13(1981)36-42.

[13] D. T Cai, J. Q. Luo, D. J. Yan, et al., Study on microstructure and properties of 5083 marine aluminum alloy weldments by double-sided single arc welding(in Chinese), Welding & Joining, 10 (2014)34-3.
