Torsion Failure Analysis of 0Cr17Ni7Al Precipitation Hardening Stainless Steel Wire

Abstract:

0Cr17Ni7Al is a precipitation hardening stainless steel, which combines the advantages of austenitic stainless steel and martensitic stainless steel. 0Cr17Ni7Al shows good corrosion resistance, excellent processability and high strength. This paper is mainly focused on the fracture morphology of 0Cr17Ni7Al wire during torsional deformation. Cracking mechanism and torsion failure reason is analyzed in detail. The results show that AlN inclusions are observed both in raw steel wire and fracture, the micro-cracks appear along the axial direction of the steel wire. The torsion strength is normally 2958MPa. but, the local stress of steel wire reaches up to5295MPa when a 0.4mm deep micro-crack locates on the surface of steel wire, and the local stress is obtained to 2953MPa around a 10μm AlN inclusion. Stress concentrating is caused by inclusions and micro-cracks, and the crack propagation lead to the torsion failure of steel wire when the local stress is beyond the torsion limit.

• Periodical: Materials Science Forum (Volume 850)
• Pages: 66-71
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.850.66
• Online since: March 2016
• Authors: Lei Chen, Ren Bo Song*, Fu Qiang Yang, Yong Jin Wang, Zhi Dong Tan, Ke Guo, Zhong Hong Wang
• Keywords: 0Cr17Ni7Al Stainless Steel Wire, AlN Inclusion, Micro-Crack, Torsion Failure

References

[1] Wang Dingwu. Development trends of stainless steel production in foreign country and advice of the stainless steel development in China. Special Steel, 1996, 17(5): 30-33.

[2] Qing Zirui, Li Maohua, Lv Jingxu, Huang Chunyu, Corrosion resistance experiment of 0Cr17Ni7Al precipitation hardening stainless steel wire. Metal of Shanghai, 1999. 7, 21(4): 20-24.

[3] Dai Xiumei, He Feng, High strength precipitation hardening stainless steel used in aviation. Transactions of Aviation & Materials, 2003, 23(zl)280.

[4] Zhao Ming, Nie Mingfen, Cai Lei, Torsion property analysis of the steel wire. Steel Wire Products, 2007, 33(6): 34-36.

[5] Cao Hongzhi, Cang Weiwei, Ma Feng, Chen Huahui, Fracture Failure Analysis of Stainless Steel Bolt, Lubrication Engineering, 2011, 36(8): 89-92.

[6] Dong Peng, Jun Shen, Qin Tang, Cuiping Wu, Yanbing Zhou, Effects of aging treatment and heat input on the microstructures and mechanical properties of TIG-welded 6061-T6 alloy joints, International Journal of Minerals, Metallurgy andMaterials, 2013. 3, 20(20)259.

DOI: 10.1007/s12613-013-0721-8

[7] Wang Chong, Zeng Yanping, Xie Xishan, Influence of characteristic inclusion parameters on crack initiation and propagation in ultra-high strength steels for aerospace application under tensile and low cyclic fatigue loading, Journal of University of Science and Technology Beijing, 2009, 31 (5): 557-562.

[8] Fan H M, Zeng Y P, Wang X S, et al. Influence of characters-the inclusion parameters on crack initiation and propagation in ultra-high strength steel under tensile load. J Aeronaut Mater. 2007, 27(4): 6.

[9] Ruan Ming, The production of 0Cr17Ni7Al spring-steel, Metal Products, 1994, 20(6): 1-8.
