Design and Experiment of Rare Earth Giant Magnetostrictive Piston Pump

Abstract:

A new piston pump structure was designed by incorporating a rare earth giant magnetostrictive material as the driving source into the basic working principles of piston pumps. The operational process of the proposed magnetostrictive piston pump was analyzed according to the overall structure design, which includes a magnetostrictive rod, drive coils, pump cavity height, one-way valve and pre-pressure mechanism. Analysis was conducted on both the seal and self-suction capacity of the proposed design. The magnetostrictive piston pump was designed to simplify the structure of a conventional piston pump by requiring fewer moving parts, a small volume, being of light weight, and utilizing a precise controllable flow, among other advantages. An experimental prototype was built and an experimental system was designed to test flow and pressure characteristics. Output flow and pressure curves were obtained to analyze the flow instability when exposed to high currents. Experimental results demonstrate that the magnetostrictive piston pump achieves a maximum output flow of 550.65mL/min when the excitation current frequency is 50Hz, and achieves a maximum output pressure of 0.65MPA when the excitation current frequency is 10Hz.

• Periodical: Materials Science Forum (Volume 852)
• Pages: 943-951
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.852.943
• Online since: April 2016
• Authors: Quan Guo Lu, Ya Peng Zhao, Qin Nie
• Keywords: Flow, Magnetostrictive, Piston Pump, Pressure, Rare Earth

References

[1] LIU Huifang, JIA Zhenyuan and WANG Fuji. Parameter Identification of Displacement Model for Giant Magnetostrictive Actuator[J]. Journal of Mechanical Engineering, 2011, 47(11): 115-120.

DOI: 10.3901/jme.2011.15.115

[2] HAN Tongpeng and LI Guoping. Magnetization-based Hysteresis Model for Magnetostrictive Actuator[J]. Journal of functional materials and devices, 2010, 16(1): 41- 46.

[3] TAO Menglun, CHEN Dingfang and LU Quanguo. Eddy Current Losses of Giant Magnetostrictors: Modeling and Experimental Analysis[J]. Journal of Mechanical Engineering, 2012, 48(13): 146-151.

DOI: 10.3901/jme.2012.13.146

[4] ZENG Haiquan, ZENG Gengxin and ZENG Jianbin. Thermal Analysis of Giant Magnetostrictive High Power Ultrasonic Transducer[J]. Proceedings of the CSEE, 2011, 31(6): 116- 120.

[5] SHI Xiao-hong. Underwater Piston Sound Source Based on Giant Magnetostrictive Material[J]. Magn Mater Devices, 2009, 5: 37~39.

[6] Li Yuesong, ZHU Yuchuan and WU Hongtao. Parameter Optimizaiton of Jet-pipe Servovalve Driven by Giant Magnetostrictive Actuator[J]. Acta Aeronautica et Astronuacica Sinica, 2011, 32(7): 1336-1343.

[7] JOSHUA Ellison, JAVANT Sirohi and INDERJITt Chopra. Investigation of active materials as driving elements of a Hydraulic Hybrid Actuator[J]. Smart Structures and Materials 2005: Smart Structures and Integrated Systems, 2005, Vol. 5764: 274-289.

DOI: 10.1117/12.600022

[8] Michael J. Rupinsky and Marcelo J. Dapino. SMART MATERIAL ELECTRO HYDROSTATIC ACTUATOR FOR INTELLIGENT TRANSPORTATION SYSTEMS[C]. 2006 ASME International Mechanical Engineering Congress and Exposition, Chicago, Illinois, USA, 2006: 721-730.

DOI: 10.1115/imece2006-14542

[9] ZHAO Yapeng. Design Theory and Experimental Study of Giant Magnetostrictive Pumps[D]. Wuhan, Wuhan University of Technology, (2013).

[10] WANG Chuanli. Research on the Nozzle Flapper Servo Valve Driven by GMM Actuator[D]. Hangzhou, Zhejiang University, (2005).

[11] WANG Chuanli CHENG Xia and AN Ping. Performance analysis of GMM high-frequency micro-pump[J]. Chinese Hydraulics and Pneumatics, 2010, 9: 70-73.

[12] LU Quanguo, ZHAO Yapeng, and ZHENG Xiaolei. Giant Magnetostrictive Pumps of elasticity[P]. China, 201320193963. 9[P]. 2013-04-17.

[13] A.M. Yu and Y. Hao. Free vibration analysis of cylindrical helical springs with noncircular cross-sections[J]. Journal of Sound and Vibration, 2011, 330 (11): 2628-2639.

DOI: 10.1016/j.jsv.2010.12.015
