Monitoring Method of Process Temperature and Vibration of Rotating Machining Tool with a Wireless Communication Holder System

Abstract:

We developed a wireless communication holder system to monitor the process temperature and vibration of a rotating machining tool. This report presents an estimation of the process temperature in end-milling and the chatter vibration when boring with it. The thermocouple is set in the end-mill tool to measure the process temperature, and the MEMS accelerometer is set in the boring tool to measure the chatter vibration. We also present an investigation of the end-mill temperature observed using infrared thermography and the vibration of the spindle using a traditional accelerometer. The proposed holder system was found to be effective to estimate the process monitoring of the rotating machining tools.

• Periodical: Materials Science Forum (Volume 874)
• Pages: 519-524
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.874.519
• Online since: October 2016
• Authors: Ryo Matsuda*, Masatoshi Shindou, Tatsuya Furuki, Toshiki Hirogaki, Eiichhi Aoyama
• Keywords: End-Mill Process, Infrared Imagery, Process Efficiency, Thermography, Tool Temperature, Tool Vibration Process Monitoring

References

[1] M. Shindou, H. Kodama, T. Hirogaki, E. Aoyama, Key Engineering. Materials, Vol. 625, (2014), pp.213-218.

DOI: 10.4028/www.scientific.net/kem.625.213

[2] N. Sugita, M. Mitsuishi, Journal of the JSPE, Vol. 72, No. 2(2006), pp.276-280 (in Japanese).

[3] T. Ueda, M. Sato b, A. Hosokawa a, M. Ozawa, CIRP Annals - Manufacturing Technology 57, (2008), p.69–72.

[4] G. Quintana, J. Ciurana, International Journal of MachineTools&Manufacture, Vol. 51, (2011), p.363–376.

[5] J. Monnin, F. Kuster, K. Wegener, Control Engineering Practice Vol. 24, (2014) , pp.156-166.
