Correlations between Defect Content, Mechanical Properties and Fractographic Investigation of AlSi9Cu3(Fe) Alloy Reference Castings

Abstract:

High Pressure Die Casting (HPDC) is a foundry process particularly suitable for high production rates and applied in several industrial fields, but the amount of scrap, caused by defects or incomplete filling, is sometimes very high. Thus it is important to know which are the main causes of defect formation and their effects on microstructure and mechanical properties. This paper presents, within the European MUSIC project, the qualitative and quantitative results of a study conducted on AlSi9Cu3(Fe) alloy castings, referred to as Horse-shoe Reference Castings, specifically designed to generate different kinds of defects with different severity levels. The work focuses on the correlations obtained between the casting mechanical properties, their defect content in terms of porosity and oxide films and the process parameters adopted, mainly second phase plunger velocity and intensification pressure. The three point bending test was carried out on the four specimens obtained from the two appendixes of the casting. The fracture surfaces were studied by scanning electron microscopy (SEM) and optical microscopy (OM) highlighting that the defect content is clearly correlated to the mechanical properties and the process parameter settings.

• Periodical: Materials Science Forum (Volume 879)
• Pages: 193-198
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.193
• Online since: November 2016
• Authors: E. Battaglia*, F. Bonollo, I. Tonello, E. Fiorese
• Keywords: Defects, High Pressure Die Casting, Horse-Shoe Shaped Casting, Process Parameter, Three Point Bending Test

References

[1] F. Bonollo, G. Timelli, N. Gramegna, High Pressure Die Casting: Contradictions and Challenges, The Journal of the Minerals, Metals & Materials Society (2015) Italy.

DOI: 10.1007/s11837-015-1333-8

[2] E. Fiorese, F. Bonollo, G. Timelli, L. Arnberg, E. Gariboldi, New classification of defects and imperfections for aluminum alloy castings, International Journal of Metalcasting (2015) Italy-Norway.

DOI: 10.1007/bf03355602

[3] W.G. Walkington, Die Casting Defects – Troubleshooting Guide, NADCA (2003) Arlington Heights, Illinois.

[4] J. Campbell, The 10 rules for good castings, in: Complete Casting Handbook, second ed. (2015) pp.535-638.

DOI: 10.1016/b978-0-444-63509-9.00010-8

[5] Information on http: /www. stacast-project. org.

[6] CEN/TR 16749, Aluminium and aluminium alloys – Classification of defects and imperfections in high pressure, low pressure and gravity die cast products (2014) pp.1-41.

DOI: 10.3403/30299762u

[7] E. Gariboldi, F. Bonollo, P. Parona, Handbook of defects in high pressure diecasting, second ed., AIM: Centro di studio pressocolata, Italy, (2010).

[8] E. Battaglia, F. Bonollo, G. Timelli, E. Fiorese, G. Kral, Correlation between process, microstructure and properties in High Pressure Die Casting Aluminum-Silicon alloys, AMPT2015 (2015) Madrid, under review.

DOI: 10.1080/2374068x.2016.1250206

[9] M. Winkler, L. Kallien, T. Feyertag, Correlation between process parameters and quality characteristics in aluminum high pressure die casting, NADCA Die Casting Congress & Exposition (2015).

[10] Information on http: /music. eucoord. com/intro/body. pe.

[11] E. Zanini, S. Barison, L. Capra, G. Timelli, F. Voltazza, Microstructure and bending properties of die-casting alloys at various chromium contents, La Metallurgia Italiana (2012) Italy.

[12] L. Lu, K. Nogita, S.D. McDonald, A.K. Dahle, Eutectic solidification and its role in casting porosity formation, JOM, Vol. 56, Issue 11 (2004) pp.52-58.

DOI: 10.1007/s11837-004-0254-8

[13] C.M. Gourlay, H.I. Laukli, A.K. Dahle, Defect band characteristics in Mg-Al and Al-Si high pressure die castings, Metallurgical and Materials Transactions A (2007) Australia.

DOI: 10.1007/s11661-007-9243-1

[14] M. S. Dargusch, G. Dour, N. Schauer, C. M. Dinnis, G. Savage, The influence of pressure during solidification of high pressure die cast aluminium telecommunications components, Journal of Materials Processing Technology, (2006).

DOI: 10.1016/j.jmatprotec.2006.05.001
