Reutilizing Sediment Soil Wastes from Water Supply Treatment Process as Replacement Materials of Non-Fired Wall Tiles

Abstract:

Sediment soil is the wastes from water supply treatment process. It leads the high burden of disposal cost to the metropolitan waterworks authority. Utilizing of sediment soil has been studied. Likewise, this research aims to utilize the sediment soil, wastes of water supply treatment process for producing non-fired wall tiles. In the experiment, four types of raw materials have been employed consisting of sediment soil, laterite soil, Portland cement type 1 and fluvial sand. Constructed formulas have been divided into two groups. Substitution of sediment soil for laterite soil is the first group, and substitution for fluvial sand is the second group. After mixing the raw materials of all formulas, forming specimens by uni-axial pressing at 100 bars with dimension 100x50x8 mm. have been carried out. Then, they have been sprayed and aged for 7, 28, and 60 days at room temperature. After that, testing the specimens’ properties has been performed based on TIS 2508-2555 standard. The formula contains 10% of sediment soil wastes offering the highest bending strength 7.51 Mpa, and 6.87% water absorption at 60-day aging. The experimental results show that adding the sediment soil to the basic composition has an effect on the bending strength and water absorption. The water absorption property can pass standard TIS 2508-2555, and bending strength nearly passes the standard. Energy saving cost has been compared with fired wall tiles at 850°C. It can save cost by $13 USD/cycle/day In addition, imaging analysis using Scanning Electron Microscopy has been employed for analysing the microstructure of specimens at different curing age for 7, 28, and 60 days.

• Periodical: Materials Science Forum (Volume 917)
• Pages: 303-310
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.917.303
• Online since: March 2018
• Authors: Ubolrat Wangrakdiskul*, Rachanon Neamlut
• Keywords: Eco-Friendly, Non-Fired Wall Tiles, Sediment Soil Utilization

References

[1] Bangkhen Water Treatment plant. Information on https: /www. mwa. co. th/ewtadmin/ewt/mwa_internet_eng/download/question/bkplant_eng. pd.

[2] D. Suriyachat, P. Vichitamornpun and W. Ruangsumret, Application of Sediment Soils, Metallurgical Technology Group, Bureau of Primary Industries, Department of Primary Industries and Mines, Country Report, Thailand, (2004).

[3] K. Boonin, S. Sarapol and S. Deesui. Properties of Lighted Weight Concrete used Sediment Soil from Water Supply Process as Coarse Aggregate, Department of Civil Engineering, Faculty of Engineering, Thesis, Khon Kaen University, (2012).

[4] N. Chatsatapattayakul, M. Wangwiang and P. Pengthamkeerati, Potential use of chemical sludge from water treatment system with cement in cement mortar and soil cement block, Rajabhat Journal of Science, Humanities & Social Sciences. 13(1), (2012).

[5] U. Wangrakdiskul, J. Wanasbodee and P. sansroi, Ceramics Vitreous China Produced by Utilizing Sediment Soil from Water Supply Treatment Process, MATEC Web of Conferences 95, 02005 (2017) DOI: 10. 1051/matecconf/2017950200.

DOI: 10.1051/matecconf/20179502005

[6] S.R. Teixeira, G.T.A. Santos, A.E. Souza, P. Alessio, S.A. Souza and N.R. Souza, The effect of incorporation of a Brazilian water treatment plant sludge on the properties of ceramic materials, Applied Clay Science, 53, (2011), p.561–565.

DOI: 10.1016/j.clay.2011.05.004

[7] C. Martínez-García, D. Eliche-Quesada, L. Pérez-Villarejo, F.J. Iglesias-Godino and F.A. Corpas-Iglesias, Sludge valorization from wastewater treatment plant to its application on the ceramic industry, Journal of Environmental Management 95, (2012).

DOI: 10.1016/j.jenvman.2011.06.016

[8] O. Kizinievic, R. Zurauskiene, V. Kizinievic and R. Zurauskas, Utilisation of sludge waste from water treatment for ceramic products, Construction and Building Materials, 41, (2013), p.464–473.

DOI: 10.1016/j.conbuildmat.2012.12.041

[9] E. Wolff , W. Keller Schwabe and S. Vieira Conceiçao, Utilization of water treatment plant sludge in structural ceramics, Journal of Cleaner Production xxx, (2014), pp.1-8.

[10] H. L. Luo, D. F. Lin, M. L. Chung and L.Y. Chen, Waste Foundry Sand Reused as Clay Replacement for Tile Manufacture, International Journal of Transportation Science and Technology, Vol 3, Issue 4, (2014) , P. 339–351.

DOI: 10.1260/2046-0430.3.4.339

[11] M. Ana, B. Juan, M. G. Eliseo and M. G. Gustavo, Energy Saving in Ceramic Tile Kilns: Cooling gas heat recovery, Applied Thermal Engineering Vol. 65, no. 1–2, (2014).

DOI: 10.1016/j.applthermaleng.2014.01.002

[12] U. Wangrakdiskul, P. Khonkaew and T. Wongchareonsin, Use of the Spent Bleaching Earth from Palm Oil Industry in Non Fired Wall Tiles, The 3rd International Symposium on the Fusion Technologies 2014 (ISFT2014), Jeonju, S. KOREA, 30 July-3 August, (2014).

DOI: 10.17703/ijact.2015.3.2.15

[13] U. Wangrakdiskul, K. Benjaratthapong and M. Jongtrakulsiri, Crushed Limestone Dust Valorization for Eco Friendly non Fired Wall Tiles, MATEC Web of Conferences, Vol. 64 (2016), http: /dx. doi. org/10. 1051/matecconf/20166407002‏.

DOI: 10.1051/matecconf/20166407002

[14] U. Wangrakdiskul, T. Kleepung. and P. Srihakham. (2008) The Possibility Study of Using Laterite Clay, Soil and Cement Interlocking for Non Fired Wall Tiles, IE Network Conference 2001, October, 20-22, Songkhla, Thailand.

[15] Er. L. Menon, Fabrication and Comparison of Mechanical Properties of Hybrid GFRP Using Epoxy Modifiers, International Research Journal of Engineering and Technology, Vol 3, Issue 5, (2016).

[16] Optimizing the Use of Fly Ash in Concrete, Information on http: /www. cement. org/docs/default-source/fc_concrete_technology/is548-optimizing-the-use-of-fly-ash-concrete. pdf‏.

DOI: 10.1520/cca10363j

[17] P. Nakkanok. Utilizing sediment soil, cullet, and compound clay for producing terracotta wall tiles, Thesis, Faculty of Engineering, King Mongkut's University of Technology North Bangkok, Thailand, (2017).
