Plasma Printing of Micro-Punch Assembly for Micro-Embossing of Aluminum Sheets

Abstract:

This paper concerned with micro-embossing of micro-cavities and micro-grooves into aluminum sheets by CNC-stamping with use of the arrayed DLC multi-punches. Both SKD11 and AISI420 steel die substrates were prepared and DLC-coated with the thickness of 10 to 15 μm. This DLC coating worked as a punch material. The two dimensional micro-patterns were printed onto this DLC film by maskless lithography. The unprinted DLC films were removed by the plasma oxidation to leave the three dimensional DLC-punch array on the steel substrate. This micro-pillared and micro-grooved DLC-punches were placed into the cassette die set for micro-embossing process by using the table-top CNC stamper. The micro-circular patterns transformed to the micro-pillars in the DLC punch by the plasma oxidation. Through the CNC-micro-embossing, this micro-texture further transferred to micro-cavities in the aluminum sheet. The dimensional accuracy of embossed micro-textures by stamping was measured by SEM and three dimensional profilometer with comparison to the tailored micro-pattern and the DLC-punch array configuration.

• Periodical: Materials Science Forum (Volume 920)
• Pages: 161-166
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.920.161
• Online since: April 2018
• Authors: Tatsuhiko Aizawa*, Kenji Wasa, Abdelrahman Farghali, Hiroshi Tamagaki
• Keywords: Aluminum Sheets, Heat Transfer, Micro-Cavity Textures, Micro-Embossing, Multi DLC-Punch Assembly, Plasma Oxidation, Plasma Printing

References

[1] H. Takahashi, Ed., Handbook of diamond like carbon coating, NTS-publishing. (2008).

[2] A. Moisala, Q. Li, T. A. Kinloch, A. H. Windle, Thermal and electrical conductivity of single- and multi-walled carbon nanotube – epoxy composites. Composite Science and Technology. 66 (10) (2006) 1285-1288.

DOI: 10.1016/j.compscitech.2005.10.016

[3] J. Robertson, Diamond-like amorphous carbon, Material Science and Engineering, 37 (2002) 129-281.

[4] D. Erdemir, C. Donnet, Tribology of diamond-like carbon films: recent progress and future prospects, J. Physic. 39 (2006) 311-327.

DOI: 10.1088/0022-3727/39/18/r01

[5] T. Aizawa, N.T. Redationo, K. Mizushima, Precise micro-texturing onto DLC coating via high-density oxygen plasma etching, Proc. 10th of ICOMM (2013) 129-132.

DOI: 10.3850/978-981-07-7247-5-338

[6] T. Aizawa, T. Fukuda, Oxygen Plasma Etching of diamond-like carbon coated mold-die for micro-texturing, Surface & Coating Technology, 215 (2013) 364-368.

DOI: 10.1016/j.surfcoat.2012.07.095

[7] T. Aizawa, Micro-texturing onto amorphous carbon materials as a mold-die for micro-forming. Applied Mechanics and Materials, 289 (2014) 23-37.

DOI: 10.4028/www.scientific.net/amm.289.23

[8] T. Aizawa, S. Amano, H. Tamagaki, Micro-texturing into thick DLC films for fabrication of micro-stamping dies, Proc. 7th AWMFT Symposium (2015, Suwa) J1-1 to 6.

[9] T. Aizawa, Micro-texturing for tribology and surface engineering in manufacturing process, Proc. 4th ISAST Conference (2016, Indonesia) 1-17.

[10] N. F. Khusnah, T. Aizawa, S. Sakti, Plasma oxidation printing onto the DLC and ceramic coatings for fabrication of micro-stamping dies. Proc. 10th SEATUC Conference, OS6 (2016, Tokyo) 19-1 to 4.

[11] T. Aizawa, M. Tamaki, T. Fukuda, Large area micro-texture imprinting onto metallic sheet via CNC stamping, J. Procedia Engineering. 81 (2014) 1427-1432.

DOI: 10.1016/j.proeng.2014.10.168

[12] T. Aizawa, T. Fukuda, Pulsewise-motion controlled stamping for micro-texturing onto aluminum sheet, J. Micro-Nano Manufacturing, ASME (2016).

DOI: 10.1115/1.4031739
