Strengthening of Reinforced Concrete Beams by Carbon Fiber Composites

Abstract:

The paper considers the results of the experimental study of the reinforced concrete beams strengthened by carbon fiber reinforced plastics (the CFRP). Eight reinforced concrete beams of the 80x160 mm section and 1500 mm designed span have been manufactured and tested. The influence of the number of the CFRP layers (strengthening power) on bearing capacity and rigidity under the static loading of beams in the thirds of the span has been studied. The results obtained indicate the increase in bearing capacity of the reinforced beams from 24% up to 55% and the increase in rigidity by 45% for the commonly adopted limiting state, i.e. achieving ultimate deformations in concrete of the compressed zone). The paper underlines the need for using anchor devices in the form of U-shaped binders to ensure the efficiency of the given method of strengthening.

• Periodical: Materials Science Forum (Volume 931)
• Pages: 379-384
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.931.379
• Online since: September 2018
• Authors: Yuri V. Ivanov*, Yuri F. Rogatnev, Igor I. Ushakov
• Keywords: Bearing Capacity, Carbon Fiber Reinforced Plastics (CFRP), Deformation, Reinforced Concrete Beam, Strengthening

References

[1] U.M. Meier, M. Deuring, H. Meier and G. Schwegler, Strengthening of structures with CFRP strips: research and applications in Switzerland, Adv. Comp. Mat. Bridges Struct. Can. Soc. Civil Eng., Montreal and Canada. 1 (1992) 243-251.

[2] T.C. Triantafillou and N. Pelvris, Strengthening of RC Beams with Epoxy-Bonded Fibre-Composite Materials, Materials and Structures. 25 (1992) 201-211.

DOI: 10.1007/bf02473064

[3] M.J. Chajes, T. Thomson, W.W. Finch and T. Januszka, Flexural strengthening of concrete beams using externally bonded composite materials, Construction and Building Materials. 8 (3) (1994) 191-201.

DOI: 10.1016/s0950-0618(09)90034-4

[4] R.V.S. GangaRao and P.V. Vijay, Bending Behavior of Concrete Beams Wrapped with Carbon Fabric. Journal of Structural Engineering. 124 (1) (1998) 3-10.

DOI: 10.1061/(asce)0733-9445(1998)124:1(3)

[5] R. Balamuralikrishnan and A.C. Jeyasehar, Flexural Behavior of RC Beams Strengthened with Carbon Fiber Reinforced Polymer (CFRP) Fabrics. The Open Civil Engineering J. 3 (2009) 102-109.

DOI: 10.2174/1874149500903010102

[6] ACI COMMITTEE (440.2R-08) (2008). Guide for the design and construction of externally bonded FRP systems for strengthening concrete structures. Farmington Hills, MI; American Concrete Institute; (2008).

DOI: 10.14359/51700867

[7] FIB (2001). Design and Use of Externally Bonded FRP Reinforcement (FRP-EBR) for Reinforced Concrete Structures. Bulletin 14, fib Task Group 9.3 FRP Reinforcement for Concrete structures,. Federation Internationale du Beton, Lausanne, Switzerland.

DOI: 10.35789/fib.bull.0014.ch01

[8] S.A. Bokarev, D.N. Smerdov, Experimental studies of bent ferro-concrete elements reinforced with composite materials, IzvestiyaVuzov. Building. 2 (2010) 112-124.

[9] E.V. Sazonov, I.Yu. Ivanov and Yu.V. Ivanov, Efficiency of reinforcement of bent ferro-concrete elements by polymers based on carbon fibers, Construction mechanics and structures. Scientific and technical journal. 1 (2010) 80-87.

[10] I.G. Ovchinnikov, Sh.N. Valiev, I.I. Ovchinnikov, V.S. Zinoviev, A.D. Umirov, Questions of reinforcement of reinforced concrete structures by composites: 1. Experimental studies of the features of reinforcement of reinforced concrete structures by composites, Internet-journal Naukovedenie,- M. 4 (2012).

DOI: 10.14359/5647

[11] SP 164.1325800.2014. Strengthening of reinforced concrete structures by FRP composites. Regulation of design, Moscow, Ministry of Construction of Russia. (2014) 50.

[12] M. Blascko, R. Nierdermeier and K. Zilch, Bond failure modes of flexural members strengthened with FRP. In Proceedings of Second International Conference on Composites in Infrastructures, Saadatmanesh, H. and Ehsani, M.R., eds., Tucson, Arizona. (1998).

[13] J. Yao, J.G. Teng, L. Lam, Experimental study on the intermediate crack debonding in FRP-strengthened RC flexural members. Advances in Structural Engineering . 8(4) (2005) 365–96.

DOI: 10.1260/136943305774353106

[14] I.Yu. Ivanov and Yu.V. Ivanov, Strength of adhesion of carbon fibers to concrete with reinforcement of bent ferro-concrete elements. 7th Int. sci. Conf. Mechanics of destruction of concrete, reinforced concrete and other building materials. RAASN, Voronezh State Agricultural Academy. Voronezh. 1 (2013).
