Studying Gas-Phase Flows in the Laser Exposure Zone during Selective Laser Melting

Abstract:

The processes occurring during selective laser melting were studied with a high-speed CCD camera. In order to record all optical in-homogeneities, the camera was integrated into optical arrangement, that realized the Schlieren-method. Within the experiment three parameters were estimated, such as powder particles opening angle, their velocity and the outflow velocity of vapor-gas jet. The influence of laser setup parameters is given. It is shown that particle size and material composition, together with laser power, affect greatly on the opening angle and velocity of powder particles emission, respectively.

• Periodical: Materials Science Forum (Volume 989)
• Pages: 806-810
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.989.806
• Online since: May 2020
• Authors: Pavel Anatolyevich Podrabinnik*, C.E. Protasov, A.V. Gusarov
• Keywords: Additive Manufacturing, Gas-Phase Jet, Optical Diagnostics, Schlieren-Method, Selective Laser Melting

References

[1] I.V. Zhirnov, P.A. Podrabinnik, A.A. Okunkova et al., Laser beam profiling: Experimental study of its influence on single-track formation by selective laser melting, Mech. Ind. 16 (2015).

DOI: 10.1051/meca/2015082

[2] I. Yadroitsev, Ph Bertrand, I. Smurov, Parametric analysis of the selective laser melting process, Appl. Surf. Sci. 253 (2007) 8064–8069.

DOI: 10.1016/j.apsusc.2007.02.088

[3] C.Y. Yap, C.K. Chua, Z.L. Dong et al., Review of selective laser melting: Materials and applications, Appl. Phys. Rev. 2 041101 (2015).

[4] I. Yadroitsev, A. Gusarov, I. Yadroitsava, I. Smurov, Single track formation in selective laser melting of metal powders, J. Mater. Process. Technol. 210 (2010) 1624.

DOI: 10.1016/j.jmatprotec.2010.05.010

[5] M.J. Matthews, G. Guss, S.A. Khairallah, A. Rubenchik, A.T. Anderson, P.J. Depond, W.E. King, Denudation of metal powder layers in laser powder bed fusion processes, Acta Mater. 114 (2016) 33–42.

DOI: 10.1016/j.actamat.2016.05.017

[6] A.V. Gusarov, A.A. Okun'kova. Peretyagin P.Y. et al. Means of optical diagnostics of selective laser melting with non-Gaussian beams, Meas Tech+, 58 (2015) 872-877.

DOI: 10.1007/s11018-015-0810-3

[7] A.V. Gusarov, I. Yadroitsev, Ph Bertrand, I. Smurov, Model of radiation and heat transfer in laser-powder interaction zone at selective laser melting., J. Heat Transfer, 131 (2009) 072101.

DOI: 10.1115/1.3109245

[8] F. Verhaeghe, T. Craeghs, J. Heulens, L. Pandelaers, A pragmatic model for selective laser melting with evaporation. Acta Mater, 57 (2009) 6006–6012.

DOI: 10.1016/j.actamat.2009.08.027

[9] S. Ly, A.M. Rubenchik, S.A. Khairallah, G. Guss, M.J. Matthews, Metal vapor micro-jet controls material redistribution in laser powder bed fusion additive manufacturing, Sci. Rep. 7 (2017) 4085.

DOI: 10.1038/s41598-017-04237-z

[10] I. Zhirnov, D.V. Kotoban, A.V. Gusarov, Evaporation-induced gas-phase flows at selective laser melting, Appl. Phys. A. 124 (2018) 157.

DOI: 10.1007/s00339-017-1532-y

[11] R.S. Khmyrov, A.P. Shevchukov, A.V. Gusarov, T.V. Tarasova Phase composition and microstructure of WC–Co alloys obtained by selective laser melting, Mech. Ind. 18 (2017) 714.

DOI: 10.1051/meca/2017059
