Characteristic Analysis on Monodrome Modal Algorithm Control and Its Application

Abstract:

Nano drive parts based on thermal deformation is a new drive method, it can afford more than 5000N feeding force, but it has great time-lag change which make it very difficult to control, so it is critical to choose control method. In order to apply monodrome modal algorithm control (MMAC) to nano feed system having large time-lag, A new step by step fitting method by the experimental results to confirm model parameters of control system was presented, and the characteristics of control system was analyzed. Simulation results show that there is periodic error generated by model building, when the number of terms (N) adopted in predicative modal of non-parametric and monotonic is lesser, i.e. little N generated periodic error and there is a lager error when the sampling point are near N
2N
3N, but with the increasing of number of terms (N), error becomes little, so comprehensive information and error depend on the number of term (N). Predicative step is related to response speed and robust characteristic, there are longer response speed and better robust characteristic, when the predicative step is added. 15nm feeding accuracy was achieved by experiments, when the MMAC was used in nano drive parts having large time-lag change.

• Periodical: Solid State Phenomena (Volumes 121-123)
• Pages: 1329-1332
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.121-123.1329
• Online since: March 2007
• Authors: Xu Xiao Hu
• Keywords: Characteristic Analysis, Monodrome Modal Algorithm Control (MMAC), Nano Control, Nano Drive Part

References

[1] Anthonis, Jan; Ramon, Herman, Linear mechanical systems and dyadic transfer function matrices, Automatica, vol. 39, no. 8, pp.1353-1363, August, (2003).

DOI: 10.1016/s0005-1098(03)00107-9

[2] Garcia-Sanz, M; Guillen, J. c; Ibarrola, J. J, Robust controller design for uncertain systems with variable time delay, Control Engineering Practice, vol. 9, no. 9, pp.961-972, September, (2001).

DOI: 10.1016/s0967-0661(01)00040-5

[3] Dougherty, Danielle; Cooper, Doug, A practical multiple model adaptive strategy for single-loop MPC, Control Engineering Practice, vol. 11, no. 2, pp.141-159, February 2003. p=1 p=2 p=4 Amount of feed f/nm Relative error (%).

DOI: 10.1016/s0967-0661(02)00106-5
