Tubular Linear Actuator as a Part of Mechatronic System

Abstract:

Electromagnetic tubular linear actuators are very important in mechatronic systems. The new construction of the linear actuator is presented in the paper. Many calculations with magnetic field analysis have been carried out for the new construction of the object. It was a five-phase permanent magnet tubular linear actuator. The static and dynamic parameters of the actuator have been calculated and measured, as well. A good correlation between the results validates the mathematical modeling of the actuator.
