Atomic Force Microscopy Measurements of Magnetostriction of Soft-Magnetic Films

Abstract:

A method for direct measuring the magnetostriction of ferromagnetic films (deposited on nonmagnetic substrates) in using an atomic force microscope was suggested. In measuring the magnetostriction for films 10 [mm] in length and 0,2 [μm] in thickness, which were deposited on substrates 200 [μm] thick, the minimum measured magnetostriction magnitude is ~10^-7. The procedure was tested for Ni and Fe films. The magnetostriction magnitudes measured for the films are comparable with those obtained by other magnetostriction-measuring methods. The effect of alloying with zirconium and nitrogen on the magnetostriction of nanocrystalline Fe films was studied.

• Periodical: Solid State Phenomena (Volume 190)
• Pages: 179-182
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.190.179
• Online since: June 2012
• Authors: E.V. Harin, E.N. Sheftel’, A.I. Krikunov
• Keywords: Atomic Force Microscopy (AFM), Fe-Based Nanocrystalline Films, Magnetostriction

References

[1] E.N. Sheftel', S.V. Komogortsev, R.S. Iskhakov et al. Investigation of the magnetic properties and magnetic structure parameters of nanocrystalline Fe79Zr10N11 films, Bulletin of the Russian Academy of Sciences: Physics, 74 (2010) 1449–1451.

DOI: 10.3103/s1062873810100382

[2] G. Stoney, The tension of metallic films deposited by electrolysis, Proceedings of the Royal Society London A, 82 (1909) 172-175.

[3] R. Watts, M.R.J. Gibbs, W.J. Karl and H. Szymczak, Finite-element modelling of magnetostrictive bending of a coated cantilever, Appl. Phys. Letters 70 (1997) 2607-2609.

DOI: 10.1063/1.118932

[4] T. Shima and H. Fujimori, An accurate measurement of magnetostriction of thin films by using nano-indentation system, IEEE Transactions on Magnetics, 35 (1999) 3832-3834.

DOI: 10.1109/20.800680

[5] A. Papageorgopoulos, H. Wang, C. Guerrero and N. Garcia, Magnetostriction measurement with atomic force microscopy: a novel approach, J. Magn. Magn. Mater. 268 (2004) 198-204.

DOI: 10.1016/s0304-8853(03)00499-2

[6] V.H. Guerrero, R.C. Wetherhold, Magnetostrictive twisting of film–substrate plates, J. Magn. Magn. Mater 279 (2004) 343-352.

DOI: 10.1016/j.jmmm.2004.02.002

[7] W. Yang, H. Liu, C. Dun, Y. Zhao and L. Dou, Variations of the Effective Magnetostriction with Annealing Conditions for Nanocrystalline Magnetic Alloys, J. Low Temp. Phys. 164 (2011) 272-278.

DOI: 10.1007/s10909-011-0371-z

[8] E.N. Sheftel', E.V. Bobylev, M.I. Petrzhik, Mechanical properties of soft magnetic films Fe79Zr9N12 by nano-indentation, 5th Eurasian scientific-practical conference The strength of heterogeneous structures, (PROST-2010) April 20-22, 2010 [in Russian].

[9] J. Betz, E. du Tremolet de Lacheisserie and L. T. Baczewski, Magnetoelastic properties of nickel thin films, Appl. Phys. Lett. 68 (1996) 132-133.

DOI: 10.1063/1.116779

[10] A. Charkaborty, K. Mountfield, G. Bellesis, D. Lambeth and M. Kryder, Search for high moment soft magnetic materials: FeZrN, J. Appl. Phys. 80 (1996) 1012-1014.

DOI: 10.1063/1.362833

[11] A. Chezan, C. Craus, N. Chechenin, T. Vystavel, L. Niesen, J. De Hosson and D. Boerma, Influence of stress and magnetostriction on the soft magnetic behavior of metallic films, J. Magn. Magn. Mater. 299 (2006) 219-224.

DOI: 10.1016/j.jmmm.2005.04.005
