Mechatronic System for Impact Tests for Aero Structures

Abstract:

The article presents the structure of the developed pneumatic propellant system for impact tests particularly conducted in the aviation. The solution is intended for the realization of experimental tests enabling the simulation and recreation of the event of collision of the aircraft, or other means of transport, with the solid object or a bird in motion. The projectile thrower has been designed in form of a 250 mm pneumatic cannon. The size and the energy parameters of the cannon enable the objects weighing several kilograms to be thrown with the speed reflecting the actual collision of the aircraft with a big bird, both in the areas of subsonic and supersonic crash speed. In order for the complex realisation of the impact tests, the structure of the test system for impact tests with the option to record the event by means of a synchronised vision path and an impact force measurement path, has been developed.

• Periodical: Solid State Phenomena (Volume 198)
• Pages: 366-371
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.198.366
• Online since: March 2013
• Authors: Andrzej Zbrowski, Andrzej Majcher
• Keywords: Air Cannon, Airplane, Bird Test, Impact Tests

References

[1] Bird Strike Damage&Windshield Bird Strike Final Report. European Aviation Safety Agency (2009).

[2] E. Cleary, R. Dolbeer, S. Wring: Wildlife Strikes to Civil Aircraft in the United States 1990-2006, Federal Aviation Administration National Wildlife Strike Database, No. 13, July (2007).

[3] Information on http: /www. wrdavis. com/bird_strike. html.

[4] Information on http: /www. wrdavis. com/hail_storm. html.

[5] B. Shorr, G. Mel'nikova, N Tishchenko: Numerical and experimental analysis of a large bird impact on fan blades for the certification purpose, INTERNATIONAL BIRD STRIKE COMMITTEE Athens, 23-27 May (2005).

[6] C-H. Tho Smith M.: Accurate bird strike simulation methodology for ba609 tiltrotor. http: /www. vtol. org/f64_bestPapers/bestPaper. pdf.

DOI: 10.4050/jahs.56.012007

[7] Y. Tipsuwan, M. -Y. Chow: Control methodologies in networked control systems. Control Engineering Practice 11 (2003) 1099-1111.

DOI: 10.1016/s0967-0661(03)00036-4

[8] A. Majcher: Model of the event driver networked control system for the diagnostics use, 10th International Science and Technology Conference: Diagnostics of Processes and Systems. Zamość, Poland, September (2011).

[9] A. Majcher, J. Przybylski, M. Mrozek, A. Zbrowski: Strain gauges synchronized measurement system, Maintenance Problems. 79 (2010), 25-32.

[10] A. Zbrowski: The testing of the prototype of the pneumatic gun. Maintenance Problems. 2011 No. 3, pp.217-234.

[11] K. Dzierżek: The digital system of the position measurement. Solid State Phenomena 2009, Vol. 147-149, pp.936-941.

DOI: 10.4028/www.scientific.net/ssp.147-149.936
