Energy Parameter Control System of Strength Machine for Material Tests under Cyclic Bending and Torsion

Abstract:

The paper presents strength machine control system for characterization of fatigue properties of materials based on a new, recently defined, energy fatigue damage parameter. It is used in new procedure for precise determination of the fatigue characteristics of materials with the controlled strain energy density parameter. The new parameter distinguishes positive and negative values strain energy density histories during variable loading. In case of modern, cyclically unstable materials the new closed-loop control system of strength machine allows to univocally establish the relevant stress-strain based fatigue characteristic under bending and torsion. This control system has been implemented with the use of National Instruments LabVIEW software. The mechatronic stand based on fatigue machine for material testing under bending moment and torsion moment has been described and preliminarily material tests have been done.

• Periodical: Solid State Phenomena (Volume 198)
• Pages: 489-494
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.198.489
• Online since: March 2013
• Authors: Leszek Kasprzyczak, Ewald Macha, Zbigniew Marciniak
• Keywords: Bending, Cyclic Loading, Fatigue of Materials, Strain Energy Density, Torsion

References

[1] Łagoda T., Macha E., Będkowski W.: A critical plane approach based on energy concepts: application to biaxial random tension-compression high-cycle fatigue regime, International Journal of Fatigue, Vol. 21, No 5 (1999) 431-443.

DOI: 10.1016/s0142-1123(99)00003-1

[2] Macha E.: A review of energy-based multiaxial fatigue failure criteria, The Archive of Mechanical Engineering, Vol. XLVIII, No 1, (2001) 71-101.

[3] Rozumek D., Marciniak Z., Lachowicz C.T.: The energy approach in the calculation of fatigue lives under non-proportional bending with torsion, International Journal of Fatigue, Vol. 32, No 8 (2010) 1343-1350.

DOI: 10.1016/j.ijfatigue.2010.02.007

[4] Macha E., Słowik J., Pawliczek R.: Energy based characterization of fatigue behaviour of cyclically unstable materials, Solid State Phenomena, Vols. 147-149 (2009) 512-517.

DOI: 10.4028/www.scientific.net/ssp.147-149.512

[5] Macha E., Kasprzyczak L., Mirek G.: Digital control systems based on Matlab/Simulink software for strength machines, Journal of Vibration and Control, Volume 18 Issue 2, February (2012) 201-208.

DOI: 10.1177/1077546311403865

[6] Słowik J., Łagoda T.: The fatigue life estimation of elements with circumferential notch under uniaxial state of loading, International Journal of Fatigue, Vol. 33 (2011) 1304-1312.

DOI: 10.1016/j.ijfatigue.2011.04.001

[7] Kasprzyczak L., Macha E.: Selection of the PID controller by automatic tuning at the control system of hydraulic fatigue stand, Mechanical Systems and Signal Processing 22(2008) 1274-1288.

DOI: 10.1016/j.ymssp.2007.08.014

[8] Rozumek D., Marciniak Z.: Control system of the fatigue stand for material tests under combined bending with torsion loading and experimental results, , Mechanical Systems and Signal Processing 22(2008) 1289 - 1296.

DOI: 10.1016/j.ymssp.2007.09.009
