Control Curves Method of Airframe Geometry Modeling

Abstract:

The paper presents the methodological approach to development of curves by selection of driving parameters with the application of the method to designing and reproduction of aircraft surfaces on the examples of both newly designed aircrafts and the ones that are already in service. The major assumptions are outlined that are necessary to develop the mathematical model of driving curves and surfaces, these assumptions served as the basis to draw up the relevant algorithms and to convert them to routines of the GRIP (Graphics Interactive Programming) language that is a part of the CAD/CAM/CAE Unigraphics system. These algorithms include the newly developed tool dedicated to design aircraft components and provided with inputs to the multi-criteria synthesis of the aerodynamic profiles of aircrafts. The study comprises also the assumptions to the newly developed algorithms dedicated to modelling of components incorporated into aircraft structures, these algorithms have been successfully implemented by the author.

• Periodical: Solid State Phenomena (Volume 199)
• Pages: 279-284
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.199.279
• Online since: March 2013
• Authors: Stanisław Kachel
• Keywords: Aircraft Structures, Parametric Modelling, Synthesis of Aircraft Body

References

[1] Björck Å., Dahlquist G., Numerical Methods, PWN Edition, Warsaw, 1987 (in Polish).

[2] Brusov W., Optimized designs of Multi-Task Aircrafts, The Scientific Library of the Institute of Aviation, Warsaw, 1996 (in Polish).

[3] Filipowski R., Ziętarski S., Programming within the POUT-APT System, The Warsaw University of Technology, 1996 (in Polish).

[4] Farin G.E., NURBS: From Projective Geometry to Practical Use, A.K. Peters, USA, (1999).

[5] Hosaka M., Modelling of Curves and Surfaces in CAD/CAM, Springer (1992).

[6] Jankowski M., Components of Computer Graphics, WNT Edition, Warsaw, 1990 (in Polish).

[7] Kachel S., Application of the GRIP CAD/CAM/CAE Language for the Reverse Engineering Parametric Modelling Method of the Aviation Structures, RRDPAE 2008, ISSN: 1425-2104.

[8] Kachel S., Engineering Graphics, the Military University of Technology (WAT), Warsaw, 2009 (in Polish).

[9] Kiciak P., Fundamentals for Modelling of Curves and Surfaces, 1st WNT Edition, Warsaw, 2009 (in Polish).

[10] Olejnik A., Kachel S., Łącki T., The Methodology for Fast Prototyping of Aircraft Models for Experimental Investigations in an Aerodynamic Tunnel, Mechanical Engineer, No. 7/2010 (in Polish).

[11] Pavlidis T., Graphics and Image Processing, WNT Edition, Warsaw 1987 (in Polish).

[12] Sibilski K., Modelling and Simulation of Dynamic Features for Motion of Flying Craft, The MH Edition, Warsaw, 2004 (in Polish).
