Growth, Optical Adsorption and Resistivity of (Ga_0.6In_0.4)₂Se₃ and (Ga_0.594In_0.396Er_0.01)₂Se₃ Single Crystals

Abstract:

The phase diagram of the Ga₂Se₃–In₂Se₃ system was investigated by differential-thermal analysis (DTA) and X-ray diffraction (XRD) method. The single crystals from the area of existence of the γ₂ phase with the compositions (Ga_0.6In_0.4)₂Se₃ and (Ga_0.594In_0.396Er_0.01)₂Se₃ were grown by a vertical Bridgman method. Absorption spectra of the grown crystals were studied. The estimated optical band gap is 1.95±0. 01 eV. The resistance of the single crystals of (Ga_0.6In_0.4)₂Se₃ (R=500 MΩ) and (Ga_0.594In_0.396Er_0.01)₂Se₃ (R=210 MΩ) was measured.
