Application of Incremental Metal Forming for Production of Aircraft Integral Panels

Abstract:

The principle and the potential of an incremental bulk metal forming method is presented in the paper. It can be used for manufacturing of the specific aircraft integral panels in a form of ribbed parts with high surface/thickness ratio. A unique laboratory device has been developed to investigate the effect of process parameters on the material flow and the press load. It utilizes tooling consisting of working rolls, a die and a punch that is divided into a number of segments. The results of preliminary numerical simulations proved that the presented forming method offers significant advantages in comparison with conventional forging.

• Periodical: Solid State Phenomena (Volume 212)
• Pages: 243-246
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.212.243
• Online since: December 2013
• Authors: Marek Tkocz, Franciszek Grosman
• Keywords: Forging, Incremental Forming, Integral Panels, Press Load, Strain Distribution, Unconventional Metal Forming

References

[1] J. Munroe, K. Wilkins, M. Gruber, Integral airframe structures (IAS) - Validated feasibility study of integrally stiffened metallic fuselage panels for reducing manufacturing costs, NASA/CR-2000-209337, Seattle, Washington, Boeing Commercial Airplane Group (2000).

[2] M. Pacchione, J. Telgkamp, Challenges of the metallic fuselage, 25th Int. Congress of the Aeronautical Sciences ICAS2006, Sept. 3-8 2006, Hamburg, Germany.

[3] K.H. Rendigs, M. Knüwer, Metal materials in Airbus A380, 2nd Izmir Global Aerospace & Offset Conference, Oct. 6-8. 2010, Izmir, Turkey.

[4] Y. Yan, M. Wan, H. Wang, L. Huang, Design and optimization of press bend forming path for producing aircraft integral panels with compound curvatures, Chinese Journal of Aeronautics, 23 (2) (2010) 274-282.

DOI: 10.1016/s1000-9361(09)60216-8

[5] F. Grosman, K.J. Kurzydłowski, J. Pawlicki, L. Tomecki, Sposób kształtowania odkuwek i przyrząd do kształtowania odkuwek matrycą segmentową (in Polish), patent No. 210904.

[6] J. Nowak, Ł. Madej, F. Grosman, M. Pietrzyk, The material flow analysis in the modified orbital forging technology, Materials Science Forum 654-656 (2010) 1622-1625.

DOI: 10.4028/www.scientific.net/msf.654-656.1622

[7] F. Grosman, Ł. Madej, S. Ziółkiewicz, J. Nowak, Experimental and numerical investigation on development of new incremental forming process, J. Mater. Process. Technol. 212 (2012) 2200-2209.

DOI: 10.1016/j.jmatprotec.2012.06.014

[8] G.E. Dieter, H.A. Kuhn, S.L. Semiatin, Handbook of workability and process design, ASM International Materials Park OH (2003) 382.

[9] M. Tkocz, F. Grosman, Parametry siłowo-energetyczne procesu kształtowania segmentowego (in Polish), Prace Naukowe Mechanika 253 (2013) 77-82.
