Transmission Proprieties of Overhead and Cable LV Power Lines – The Comparison in the Frequency Spectrum from 3 kHz to 150 kHz

Abstract:

In the present paper, the comparison results of two main kinds of the power lines are presented, namely, overhead lines and cable lines. The analysis was done in the low-voltage mains network in the frequencies identified by the CENELEC organization for a narrowband transmission using low-cost PLC modems. The currently data transmission with the use of the PLC technique finds increasing use in the area of the communication for the Smart Grid, especially because of Smart Metering and Smart Lighting systems development. Independently form the implementation of the PLC transmission technique, a process of replacement of overhead lines with cable ones is carried out. Undoubtedly this process must have an influence on the transmission prosperities over the mains network. This paper is aimed to show differences in the secondary transmission parameter of the two main constructional types of low-voltage lines, which have the same electro-power parameter. The influence of these differences on the transmission quality is also discussed. The study has been limited to aluminium and copper wires and was made in the low-voltage mains network.

• Periodical: Solid State Phenomena (Volume 237)
• Pages: 251-256
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.237.251
• Online since: August 2015
• Authors: Piotr Kiedrowski*
• Keywords: Cable Lines, Overhead Lines, Power-Line Communications, Skin Effect, Wired Lines

References

[1] R.A. Chipman, Theory and problems of transmission lines, (Schaum's outline series). McGraw-Hill 1968, 236 pages.

[2] T. A. Short, Electric Power Distribution Handbook. Second Edition. CRC Press Inc. 2014, 898 pages.

[3] S.F. Bush, Smart Grid: Communication-Enabled Intelligence for the Electric Power Grid. Wiley-IEEE Press 2014, 570 pages.

DOI: 10.1002/9781118820216

[4] EN 50065-1: 2011, Signalling on low-voltage electrical installations in the frequency range 3 kHz to 148. 5 kHz, General requirements, frequency bands and electromagnetic disturbances, (2011).

DOI: 10.3403/00994816

[5] D. Cooper, T. Jeans, Narrowband, Low Data Rate Communications on the Low-Voltage Mains in the CENELEC Frequencies—Part I: Noise and Attenuation. IEEE Trans. on Power Delivery 2002, vol. 17, no. 3, pp.718-723.

DOI: 10.1109/tpwrd.2002.1022794

[6] D. Cooper, T. Jeans, Narrowband, Low Data Rate Communications on the Low-Voltage Mains in the CENELEC Frequencies— Part II: Multiplicative Signal Fading and Efficient Modulation Schemes. IEEE Trans. on Power Delivery 2002, vol. 17, no. 3, pp.724-729.

DOI: 10.1109/tpwrd.2002.1022795

[7] P. Kiedrowski, Measurement method of the LV network for the PLC PRIME transmission and its application. Przeglad Elektrotechniczny 2015, vol. 91, no. 4, pp.99-103.

DOI: 10.15199/48.2015.04.23

[8] M. Hoch, Comparison of PLC G3 and PRIME. 2011 IEEE International Symposium on Power Line Communications and Its Applications (ISPLC) 2011, pp.165-169.

DOI: 10.1109/isplc.2011.5764384

[9] A. Cataliotti, V. Cosentino, D. Di Cara and G. Tinč, Oil-Filled MV/LV Power-Transformer Behavior in Narrow-Band Power-Line Communication Systems. IEEE Trans. Instr. & Measur. 2012, vol. 61, no. 10, pp.2642-2652.

DOI: 10.1109/tim.2012.2209911

[10] W. Nowicki W, Podstawy teletransmisji. T. 1. Wydawnictwa Komunikacji i Łączności 1971, 684 pages.

[11] P. Kiedrowski, LV Network Modelling For Smart Lighting Control Systems Over PLC. Rynek Energii 2015, vol. 116, no. 1, pp.108-113.

[12] B. Marciniak, T. Marciniak, Z. Lutowski, S. Bujnowski, Usage Of Digital Image Correlation in Analysis of Cracking, Image Processing and Communications 2012,. vol. 17, no. 3, pp.21-29.

DOI: 10.2478/v10248-012-0019-x
