Flexible Tunable Interdigital Transducer for Lamb Wave Generation

Abstract:

In this paper a novel concept of the MFC based IDT, Tunable Interdigital Transducer (T-IDT), is presented. The proposed transducer is the extension of the MFC based IDT, where the solid comb electrodes are replaced by series of discrete, stripe electrodes which can be connected independently into the groups and connected to the power source. The span between the centers of the electrodes' groups connected to the same phase are corresponding to the nominal wavelength of the wave excited by the transducer. This makes possible matching to different wavelengths without a need of physical changes of the electrodes’ layout.

• Periodical: Solid State Phenomena (Volume 251)
• Pages: 120-125
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.251.120
• Online since: July 2016
• Authors: Michał Mańka*
• Keywords: Damage Detection, IDT, Lamb Waves, NDT, SHM, Transducer, Ultrasonic Waves

References

[1] A. Raghavan and C. E. Cesnik, Review of Guided-wave Structural Health Monitoring, The shock and vibration digest, vol. 2, no. 39, pp.91-114, March (2007).

DOI: 10.1177/0583102406075428

[2] S. Boonsang, B. Dutton and R. J. Dewhurst, Modelling of magnetic fields to enhance the performance of an in-plane EMAT for laser-generated ultrasound, Ultrasonics, no. 44, pp.657-665, (2006).

DOI: 10.1016/j.ultras.2006.05.124

[3] R. Murayama and K. Mizutani, Conventional electromagnetic acoustic transducer development for optimum Lamb wave modes, Ultrasonics, no. 40, pp.491-495, (2002).

DOI: 10.1016/s0041-624x(02)00164-6

[4] W. J. Staszewski, B. C. Lee, L. Mallet and F. Scarpa, Structural health monitoring using scanning laser vibrometry: I. Lamb wave sensing, Smart Materials and Structures, no. 13, pp.251-260, (2004).

DOI: 10.1088/0964-1726/13/2/002

[5] C. Cosenza, S. Kenderian, B. Djordjevic, R. Green Jr. and A. Pasta, Generation of narrowband antisymmetric Lamb waves usinga formed laser source in the ablative regime, IEEE Transactions on Ultrasonics, Ferroelectrics, and Frequency Control, vol. 1, no. 54, pp.147-156, (2007).

DOI: 10.1109/tuffc.2007.220

[6] M. Mańka, M. Rosiek, A. Martowicz, T. Stępiński and T. Uhl, Lamb wave transducers made of piezoelectric macro-fiber composite, Structural Control and Health Monitoring, vol. 8, (2013).

DOI: 10.1002/stc.1523

[7] M. Mańka, M. Rosiek, A. Martowicz, T. Stepinski and T. Uhl, Elastic Interdigital Transducers for Lamb Wave Generations, Solid State Phenomena, no. 198, pp.307-312, (2013).

DOI: 10.4028/www.scientific.net/ssp.198.307

[8] J. K. Na and J. L. Blackshire, Interaction of Rayleigh surface waves with a tightly closed fatigue crack, NDT&E International, no. 43, pp.432-439, (2010).

DOI: 10.1016/j.ndteint.2010.04.003

[9] J. K. Na, J. L. Blackshire and S. Kuhra, Design, fabrication and characterization of single-element interdigital transducers for NDT applications, Sensors and Actuators A, no. 148, pp.359-365, (2008).

DOI: 10.1016/j.sna.2008.08.018

[10] P. D. Wilcox, Lamb Wave Inspection of Large Structures Using Permanently Attached Transducers, London: Imperial College of Science, Technology and Medicine, (1998).

[11] M. Mańka, M. Rosiek, A. Martowicz, T. Stępiński and T. Uhl, Ultrasonic piezoelectric transducer design and control methods,. PL Patent PL 399163 A1, (2013).
