Dynamic Simulation of Internal Support of Remote Controlled Weapon Station

Abstract:

In the paper a concept of internal support of remote operated weapon station mounts on civil vehicle Toyota Landcruiser L200 was presented. The support was placed inside the standard vehicle structure. The geometry of internal surfaces of structured was resembled with the use of 3D laser scanner. Designed additional support structure was used to simulate the impulsive load by shooting 12.7 machine gun equipped with muzzle brake. Results of simulation were presented and discussed.

• Periodical: Solid State Phenomena (Volume 251)
• Pages: 200-205
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.251.200
• Online since: July 2016
• Authors: Artur Iluk*, Tadeusz LEWANDOWSKI, Jerzy PTAK, Cezary BOROWIECKI
• Keywords: Dynamic Simulation, FEM, Recoil Impulse, Remote Operated Weapon Station, Reverse Engineering

References

[1] Jamroziak K., Kosobudzki M., Determining the torsional natural frequency of underframe of off-road vehicle with use of the procedure of operational modal analysis, Journal of Vibroengineering 14 (2), (2012).

[2] Jamroziak K., Kosobudzki M., Ptak J., Assessment of the comfort of passenger transport in special purpose vehicles, Eksploatacja i Niezawodność - Maintenance and Reliability 15, (2013).

[3] Kerkhoff, J. F., et al. An investigation into vehicle frontal impact stiffness, BEV and repeated testing for reconstruction,. No. 930899. SAE Technical Paper, (1993).

DOI: 10.4271/930899

[4] Iluk, A., Method of evaluating the stiffness of a vehicle with respect to the risk of explosion, Eksploatacja i Niezawodność - Maintenance and Reliability 16 (2), (2014).

[5] Bocian M., Kulisiewicz M., Method of identifying nonlinear characteristic of energy dissipation in dynamic systems with one degree of freedom, Archives of Civil and Mechanical Engineering 14 (3), (2014).

DOI: 10.1016/j.acme.2013.11.006

[6] Sansoni, G., Franco D., Three-dimensional optical measurements and reverse engineering for automotive applications., Robotics and Computer-Integrated Manufacturing 20(5), 2004, 359-367.

DOI: 10.1016/j.rcim.2004.03.001

[7] Hallquist J. O., LS-Dyna. Theoretical manual. California Livermore Software Technology Corporation, (1998).

[8] Harinder J., Wereley N. Optimal Control of Gun Recoil Using Magnetorheological Dampers., ASME 2012 Conference on Smart Materials, Adaptive Structures and Intelligent Systems. American Society of Mechanical Engineers, (2012).

DOI: 10.1115/smasis2012-8189

[9] Naik R., Singru P., Resonance, stability and chaotic vibration of a quarter-car vehicle model with time-delay feedback, Communications in Nonlinear Science and Numerical Simulation 16 (8), 2011, 3397–3410.

DOI: 10.1016/j.cnsns.2010.11.006

[10] Rusiński E., Iluk A., Stańco M., Numerical and experimental analysis of a truck frame, Innovative simulation systems / eds. Aleksander Nawrat, Karol Jędrasiak. Cham [i in. ], Springer 2016, 217-230.

DOI: 10.1007/978-3-319-21118-3_12
