Effect of Sintering Heating Rate on CaCu₃Ti₄O₁₂ Formation

Abstract:

CaCu₃Ti₄O₁₂ (CCTO) is an electroceramic material with complex cubic perovskite-like oxide. It possessed a giant dielectric constant of about 10⁵ over a wide temperature range (100-600 K). In this work, CCTO was synthesized through solid state method. The effect of different heating rate during sintering process was studied. The raw materials - CaCO₃, CuO and TiO₂ were wet ball milled for 24 hours and calcined at 900 °C for 10 hours. Then the calcined powder was pressed into pellet shape at 300 MPa. Sintering was done at 1040 °C for 12 hours with different heating rates: 3, 5 and 10 °C/min. The phase formation and surface morphology was investigated by X-Ray Diffraction (XRD) and Field Emission Scanning Electron Microscope (FESEM), respectively. The density was measured by Archimedes Principle. XRD pattern proves the CCTO single phase formation for the calcined powder and sintered pellet. The SEM images show the different grain size for different heating rate. The density of the pellet was found to be reduced when faster sintering heating rate was used.

You might also be interested in these eBooks

Current Trends in Materials Engineering II

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 264)

Pages:

173-176

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.264.173

Citation:

Cite this paper

Online since:

September 2017

Authors:

Julie Juliewatty Mohamed*, Muhammad Azwadi Sulaiman, Muhammad Qusyairie Saari, Munirah Muhammad Zain, Shafiza Afzan Sharif, Saniah Abdul Karim, Ahmad Kamil Fakhruddin Mokhtar, Hasmaliza Mohamad, Mohd Fadzil Ain, Mohd Fariz Ab Rahman, Fatin Khairah Bahanurdin

Keywords:

CCTO, Microstructure, Phase Formation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] M.A. Subramanian, D. Li, N. Duan, B.A. Reisner, A.W. Sleight, High dielectric constant in ACu3Ti4O12 and ACu3Ti3FeO12 phases, J. Solid State Chem. 151 (2000) 323-325.

DOI: 10.1006/jssc.2000.8703

Google Scholar

[2] M.F. Ab Rahman, M.J. Abu, M.F. Ain, J.J. Mohamed, Z.A. Ahmad, Effect of calcination temperature on dielectric properties of CaCu3Ti4O12 ceramics, P. Chemistry. 19 (2016) 910-915.

DOI: 10.1016/j.proche.2016.03.134

Google Scholar

[3] J.J. Mohamed, S.D. Hutagalung, Z.A. Ahmad, Influence of sintering parameters on melting CuO phase in CaCu3Ti4O12, J. K. Saud Univ. – Eng. Sci. 25 (2013) 35-39.

DOI: 10.1016/j.jksues.2011.10.001

Google Scholar

[4] J.J. Mohamed, S.D. Hutagalung, Z.A. Ahmad, Different sintering time effect on the formation and dielectric properties of CaCu3Ti4O12, Procee. 6th Nat. Semi. Neu. X-ray, 4 (2005) 82-85.

Google Scholar

[5] R.A. Zaman, M.J. Abu, S.A. Karim, J.J. Mohamed, M.F. Ain, Z.A. Ahmad, Synthesize CCTO using different mixing media, Mat. Sci. For. 840 (2016) 87-90.

DOI: 10.4028/www.scientific.net/msf.840.87

Google Scholar

[6] S.D. Hutagalung, M.I. M Ibrahim, Z.A. Ahmad, Microwave assisted sintering of CaCu3Ti4O12, Cer. Int. 34 (2008) 939-942.

DOI: 10.1016/j.ceramint.2007.09.074

Google Scholar

[7] Y.C. Liou, Effect of heating rate on properties of Pb(Mg1/3Nb2/3)O3 ceramics produced by the reaction-sintering process, Mat. Lett. 58 (2004) 944-947.

DOI: 10.1016/j.matlet.2003.07.041

Google Scholar

[8] J.W. Lee, J.H. Koh, Grain size effects on the dielectric properties of CaCu3Ti4O12 ceramics for supercapacitor applications, Ceram. Int. 41 (2015) 10442-10447.

DOI: 10.1016/j.ceramint.2015.04.109

Google Scholar

[9] S.G. Fritsch, T. Lebey, M. Boulos, B. Durand, Dielectric properties of CaCu3Ti4O12 based multiphased ceramics, J. Europ. Ceram. Soc. 26 (2006) 1245-1257.

DOI: 10.1016/j.jeurceramsoc.2005.01.055

Google Scholar

[10] K. Meepom, T. Yamwong, S. Pinitsoontom, V. Amomkitbamrung, P. Thongbai, Grain size independence of giant dielectric permittivity of CaCu3Ti4-xScxO12 ceramics, Ceram. Int. 40 (2014) 15897-15906.

DOI: 10.1016/j.ceramint.2014.07.118

Google Scholar

[11] H. Guo, W. Gao, J. Yoo, The effect of sintering on the properties of Ba0. 7Sr0. 3TiO3 ferroelectric films produced by electrophoretic deposition, Mat. Lett. 58 (2004) 1387-1391.

DOI: 10.1016/j.matlet.2003.09.033

Google Scholar

[12] D.C. Sinclair, T.B. Adams, F.D. Morrison, A.R. West, CaCu3Ti4O12: One-step internal barrier layer capacitor, App. Phys. Lett. 80 (2002) 2153-2155.

DOI: 10.1063/1.1463211

Google Scholar
