Behaviour of T91 Steel Oxide Scale Exposure to Temperature at 540°C for Different Exposure Duration

Abstract:

Grade T91 steel is one of a common material used for construction of superheater tubes in power generation boiler. In general, superheater tubes that operates in subcritical boiler are expose to operating temperatures in the range between 540°C to 580°C. Exposure to high temperature makes this steel subject to formation of oxide scale which can cause detrimental effect on the material properties. Excessive formation of oxide scale on internal surface of superheater tube can cause overheating damage at early stage of the boiler operation. This study was conducted to examine the behaviour of oxide scale forms on T91 steel for specimens exposed to temperature of 540°C for 200, 400, 600, 800 and 1000 hours holding time. The oxidation kinetic was identified as parabolic and the oxide scale was observed having 3 different layers which are haematite (Fe₂O₃), magnetite (Fe₃O₄) and spinel _(Fe,Cr)2O₃. The oxide scales layers were observed separated by voids and crack which are growing in size over time.

You might also be interested in these eBooks

Current Trends in Materials Engineering II

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 264)

Pages:

160-164

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.264.160

Citation:

Cite this paper

Online since:

September 2017

Authors:

Mohamad Nadzir Suraya*, Amrin Astuty, B. Hariffin, Roslina Mohammad

Keywords:

Oxide Scale, T91 Steel

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] P. J. Ennis and W. . Quadakkers, 9-12 % Cr steels : application limits and potential for further development, in Advanved materials for 21st centiry turbine and power plant, 2001, p.265–275.

Google Scholar

[2] D. Laverda, T. Gomez-Acebo, F. Castro, and Dummy, Continuous and cyclic oxidation of T91 ferritic steel under steam, Corros. Sci., vol. 46, no. 3, p.613–631, (2004).

DOI: 10.1016/s0010-938x(03)00173-2

Google Scholar

[3] B. N and M. G. H, Introduction to High Temperature Oxidation of Metal.

Google Scholar

[4] N. Nishimura, N. Komai, Y. Hirayama, and F. Msuyama, Japanese experience with steam oxidation of advanced heat-resistant steel tubes in power boilers, Mater. High Temp., vol. 22, no. 1–2, p.3–10, (2005).

DOI: 10.3184/096034005782750554

Google Scholar
