Study of Residual Stresses and Surface Hardening in Tubes for Nuclear Steam Generators

Abstract:

The quality of heat-exchange tubes is one of the most important factors affecting the technical condition and the durability of steam generators at nuclear power plants. The combined influence of the aggressive environment and stresses in heat-exchange tubes during the exploitation of steam generators leads to corrosive cracking of tubes. This results from the residual stresses (RS) stretching tube walls. The production of heat-exchange tubes involves the following operations: boring and grinding hot-rolled pipe billet, cold rolling middle-sized pipes, heating, rolling final-sized pipes, straightening, electro-polishing the inner surface and burnishing the outer surface, checking the final quality. The operation modes of straightening and burnishing predetermine the residual stresses in pipes in the delivery state. The paper presents the results of the studies on the residual stresses and surface hardening caused by the finishing operations. The paper also shows the need for exceptions to the production techniques for heat-exchange pipes, i.e. a series of operations increasing tensile residual stresses.

• Periodical: Solid State Phenomena (Volume 265)
• Pages: 53-59
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.265.53
• Online since: September 2017
• Authors: M.A. Rozenbaum, Andrey V. Serebryakov, Ivan Bazhukov, Georgy V. Shimov*
• Keywords: Finishing Operations, Heat Exchanger Pipes, Residual Stresses, Surface Hardening

References

[1] G.P. Karzov, VVER reactors lifetime increase based on construction materials improvement, Proc. of the 8th Int. Conf. On A-plants with VVER safety securing, Podolsk, (2013).

[2] G.P. Karzov, Dynamics evaluation of VVER-1000 steam generator heat exchanger pipes damages appearance and development in operating conditions, Information on www. gidropress. podolsk. ru/files/proceedings/seminar7/documents/f63. pdf.

[3] G.P. Karzov, Main heat exchanger pipes damages mechanisms in various exploitation stages of VVER-1000 type steam generators, Proc. of the 7th Int. Conf. On horizontal steam generators, Information on www. gidropress. podolsk. ru /files / proceedings/ seminar7/ seminar7/authors. htm.

[4] I.M. Neklyudov, Researching reasons of corrosion defects appearance in VVER-1000 steam generators heat exchanger pipes, Proc. Int. Conf. On South-Ukraine A-plant steam generators heat exchanger pipes corrosion damages: Sevastopol national University of atomic energy and industry collected articles, (2003).

[5] A.E. Fedoseev, T.M. Bulanova, U.D. Goncharenko, Researching Balakovo A-plant's second part steam generator heat exchanger pipes damages origin, New technologies for energetics, industry, and construction: collected articles. Atomic reactors scientific research Institute, Dimitrovgrad, (1998).

[6] I.A. Birger, Residual stresses, State scientific and technical publishing office engineering literature, (1963).

[7] S.P. Burkin, G.V. Shimov, An.V. Serebryakov, Al.V. Serebryakov, Effect of electrocontact heating with simultaneous tension on the residual stresses in stainless-steel pipes, Metallurgist, 59 (2015) 693-697.

DOI: 10.1007/s11015-015-0160-z

[8] S.P. Burkin, G.V. Shimov, An.V. Serebryakov, Al.V. Serebryakov, Unit for heat treatment and straightening of pipes for nuclear steam-generators, Metallurgist, 60 (2016) 61-68.

DOI: 10.1007/s11015-016-0252-4

[9] G.V. Shimov, M.A. Rozenbaum, Al.V. Serebryakov, An.V. Serebryakov, Тhe method for measuring residual stress in stainless steel pipes, Journal of Chemical Technology and Metallurgy, 51 (2016) 458-464.

[10] R Development Core Team R: A language and environment for statistical computing. R Foundation for Statistical Computing, Vienna, Austria, (2011).
