Investigation of the Hydrogen Stratification of the Metal of the Active Gas Pipeline

Abstract:

One of the most common types of metal destruction in the oil and gas industry is hydrogen embrittlement. Hydrogen corrosion is a complex of negative effects of hydrogen on steel, leading to the destruction of metal structures. Hydrogen passes through a defect-free metal, without lingering in it. In the presence of defects, hydrogen is retained in the metal forming a brittle solid solution, metal stratification along the segregation streamer, blistering. Studies of the metal of a gas pipeline made of steel 09G2S are presented in the article. The sample was selected from the local zone of destruction in the condensate collector, the metal of the pipe had typical for hydrogen corrosion stratifications. The scope of the study was identification of the most dangerous part of hydrogen corrosion on the sample taken from the local zone of destruction. Studies on the chemical composition and mechanical properties of 09G2S steel were also carried out. Stress-related characteristics of the metal microstructure of the failed gas pipeline were obtained and the character of the destruction progress was revealed. The presence of sulfides cluster in the metal of studied pipe was determined applying metallographic method for determining nonmetallic inclusions.

• Periodical: Solid State Phenomena (Volume 284)
• Pages: 1302-1306
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.284.1302
• Online since: October 2018
• Authors: O.A. Nasibullina*, A.G. Gareev, Rif G. Rizvanov
• Keywords: Hydrogen Corrosion, Hydrogen Embrittlement, Metal Stratification/Destruction, Microhardness, Microstructure

References

[1] A.G. Gareev, R.G. Rizvanov, O.A. Nasibullina , Corrosion and protection of metals in the oil and gas industry, Gilem, Ufa, (2016).

[2] A.G. Gareev, O.A. Nasibullina, R.G. Rizvanov, Investigation of hydrogen metal embrittlement, destructive metalwork, Problems of gathering, treatment and transportation of oil and oil products. 107(1) (2017) 107-115.

[3] I.G. Abdullin, A.G. Gareev, Corrosion fatigue durability of pipe steel in carbonate-bicarbonate media, Fiziko-Khimicheskaya Mekhanika Materialov. 29)5) (1993) 97-98.

DOI: 10.1007/bf00558780

[4] A.S. Tyusenkov, Chemical resistance of steel 13CrV, Steel. 2 (2016) 53-57.

[5] I.G. Abdullin, A.G. Gareev, Corrosion-fatigue durability of pipe steel in carbonate-bicarbonate medium, Materials Science. 29(5) (1994) 539-541.

DOI: 10.1007/bf00558780

[6] A.S. Tyusenkov, A.V. Rubtsov, R.R. Tlyasheva, Heat Resistance of Certain Structural Steels, Solid State Phenomena. 265 (2017) 868-872.

DOI: 10.4028/www.scientific.net/ssp.265.868

[7] A.G. Gareev, O.A. Nasibullina, I.G. Ibragimov, Evaluation of the performance of pipes with defects of corrosive origin, Problems of gathering, treatment and transportation of oil and oil products. 104(2) (2016) 126-136.

[8] R.G. Rizvanov, R.G. Abdeev, N.L. Matveev, R.G. Ryskulov, A.I. Shenknekht A.F. Insafutdinov, Effect of the geometry of the shell/elliptical-bottom contact zone on the stress state of pressure vessels, Chemical and Petroleum Engineering. 36 (2000).

DOI: 10.1007/bf02463460

[9] A.G. Gareev, Bases of corrosion of metals, USPTU Ufa, (2016).

[10] I.R. Kuzeev, I.G. Ibragimov, M.I. Bayazitov, S.N. Davydov, I.R. Khairudinov, Steel corrosion prevention in coking residual petroleum stocks, Chem. and Technology of Fuels and Oils. 22(3) (1985) 111-113.

DOI: 10.1007/bf00726125

[11] A.S. Tyusenkov, S.E. Cherepashkin, Scale Inhibitor for Boiler Water Systems, Russian J. of Applied Chem. 87(9) (2014) 1240-1245.

DOI: 10.1134/s1070427214090080

[12] I.G. Ibragimov, R.G. Vil'danov, Measuring stresses in welded joints by the remagnetisation loss method, Welding International. 21(2) (2007) 139-141.

DOI: 10.1533/wint.2007.3770

[13] Е.М. Gutman, I.G. Abdullin, D.E. Bugai, Kinetics of microdistortion changes of the crystal lattice and electrochemical behavior of austenitic steel during low-cycle corrosion fatigue, Protection of Metals and Physical Chem. of Surfaces. 18(3) (1982).

[14] D.V. Karetnikov, R.G. Rizvanov, A.M. Fairushin, K.S. Kolokhov, Increasing the reliability of oil and gas equipment working in the conditions of steep temperature gradients, Welding International. 27(7) (2013) 557-560.

DOI: 10.1080/09507116.2012.715949
