Photometric Method of Diagnosis of Bearing Units Operating with Hydrocarbon Mixtures

Abstract:

The article is devoted to the diagnosis of bearing units working with hydrocarbon mixtures. The diagnostic is based on the photometric method. This method allows you to determine the internal damage to the bearing unit at the stage of the appearance of the microcrack. The photometric method is based on changing the color of the indicator fabric. As the indicator substance, a bromine solution was used which had a dark brown color. If there is a leak, the hydrocarbon reacts with bromine molecules and a bright spot appears on the tape. Indicator fabric is applied to the bearing unit during assembling.The material of the article contains a model of the physicochemical process, which is the basis of the photometric method. Various stages of leakage of hydrocarbon mixtures through microcracks were studied. The results of the experimental studies are consistent with the theoretical propositions. The proposed diagnostic method can be used as a method for non-destructive testing of bearing units.

• Periodical: Solid State Phenomena (Volume 284)
• Pages: 1342-1348
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.284.1342
• Online since: October 2018
• Authors: E.N. Gryadunova*, R.N. Polyakov, N.V. Tokmakov
• Keywords: Bearing Units, Hermeticity, Limiting Hydrocarbons, Microcrack, Working Substance

References

[1] R. Polyakov, Increase of dynamic qualities and a resource of support units of rotors by combination of rolling and sliding bearings, Orel, (2005).

[2] R. Polyakov, Dynamic qualities and resource of combined support units, Saarbrucken, Germany, (2012).

[3] R. Polyakov, M. Bondarenko, D. Shutin, L. Savin, The approach to building the algorithm for controlling rotor motion in a hybrid mechatronic bearing, Vibroengineering PROCEDIA, 8 (2016) 219-224.

[4] L. Savin, Mechatronic bearing units, Saarbrucken, Germany, (2012).

[5] R. Polyakov, Interaction of Dynamic Characteristics of Rolling-Element and Fluid-Film Bearings in Hybrid Bearings, Procedia Engineering, 206 (2017) 61-67.

DOI: 10.1016/j.proeng.2017.10.438

[6] R. Polyakov, L. Savin, D. Shutin, Peculiarities of Reactions Control for Rotor Positioning in an Active Journal Hybrid Bearing, International Journal of Mechanics, 10 (2016) 62-67.

[7] A. Gorin, Substantiation of the parameters of the pressure and shock mechanisms with a volumetric hydraulic drive of the machine for the formation of wells in the ground, Orel, (2012).

[8] Systems of nondestructive testing. Types (methods) and technology of nondestructive testing: Scientific and Technical Center for Safety in Industry of Gosgortechnadzor in Russia, Moscow, (2003).

[9] A new directory of chemist and technologist. Chemical balance, property of solutions. A series of books for specialists, (2004).

[10] E. Gryadunova, Control of the hermeticity of products filled with limiting hydrocarbons, Orel: State University – ESPC, (2015).

[11] A. Gorin Testing products filled with the limiting hydrocarbons for leaks, Orel, (2016).

[12] E. Gryadunova, Photometric method and means for controlling the hermeticity of products with vapor-liquid filling by hydrocarbons, Orel, (1998).

[13] M. Gorina, Control of flexible pipelines for leaks, Fundamental and applied problems of technology and technology. 1 (2016) 143-148.

[14] A. Vigasin, The rate constant for the dissociation of diatomic molecules and quasi-two-atom diameters, Moscow: Moscow State University, (2000) 96-101.

[15] A. Vakhrushev, Modeling of processes of interaction of nanoparticles with microcracks, The journal "Chemical Physics and Mesoscopy. Izhevsk, 307-312.

[16] E. Gryadunova, Kinetic equation for the distribution of particles in a thermodynamic equilibrium medium, News of Orel State Technical University. Mechanical engineering. Instrument making, 1 (2006) 13-14.
