Optimal Shape Selection of Heat Exchangers Surfaces during Convective Heat Transfer

Abstract:

The article contains the results of a research in constructing of modern heat exchangers form of heat exchanging surfaces and modes of heat media flux, providing minimum area (size) of heat exchanging apparatus. Decreasing of heat-transferring area is achieved by using different techniques of intensification of convective heat exchange. Intensification of the heat exchange is accompanied by increasing of energy consumption for pumping the coolant. It is concluded that under the conditions of turbulent flow, the transport mechanism does not strongly depend on the shape of the perturbations introduced into the flow, while the tendency to approach the dependences is common to the curves for the considered surfaces, and the experimental data obtained on pipes with a periodic section of the flow cross-section along the length. Using surfaces creating channels with a greater coefficient of hydraulic resistance when creating a compact heat exchangers, which corresponds to surfaces for which the principle of trans-verse flow is realized.

• Periodical: Solid State Phenomena (Volume 284)
• Pages: 1337-1341
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.284.1337
• Online since: October 2018
• Authors: V. Konukhov*, S. Mukhanov, G. Konukhova
• Keywords: Compact Heat Exchanger, Heat Transfer Enhancement, Optimal Shape Design

References

[1] Morimoto, Kenichi & Suzuki, Yuji & Kasagi, Nobuhide, Optimal Shape Design of Compact Heat Exchangers Based on Adjoint Analysis of Momentum and Heat Transfer, Journal of Thermal Science and Technology 5 (2010) 24-35.

DOI: 10.1299/jtst.5.24

[2] Najla El Gharbi, Abdelhamid Kheiri, Momammed El Ganaoui, Ryan Blanchard, Numerical optimization of heat exchangers with circular and non-circular shapes, In Case Studies in Thermal Engineering, 6 (2015) 194-203.

DOI: 10.1016/j.csite.2015.09.006

[3] S. Jayavel, Shaligram Tiwari, Numerical study of heat transfer and pressure drop for flow past inline and staggered tube bundles, International Journal of Numerical Methods for Heat & Fluid Flow, 8(19) (2009) 931-949.

DOI: 10.1108/09615530910994432

[4] Shinya Aiba, Hajime Tsuchida, Terukazu Ota, Heat Transfer around Tubes in Staggered Tube Banks, Bulletin of JSME, (2008).

DOI: 10.1299/jsme1958.25.927

[5] Seok-Jin Oh , Kwan-Soo Lee & Seung-Jae Moon, Optimal Design of a Parallel-Flow Heat Exchanger Using a Response Surface Methodology, Numerical Heat Transfer, Part A: Applications An International Journal of Computation and Methodology, 4(49) (2006).

DOI: 10.1080/10407780500430926

[6] T.Y. Gorskaya, Hydrodynamics of laminar flow of a viscous liquid in heat-exchange devices with a rotating working surface of the confuser-diffuser, type. PhD thesis, (2004).

[7] T.A. Bubnova, Liquid systems of influence on reactivity of channel nuclear reactors. PhD thesis, (2006).

[8] V.G. Konukhov, G.V. Konukhov, Thermophysics of Nuclear Energy Engines, Moscow, «Yanus-K», (2009).

[9] G.V. Konukhov, A.I. Petrov, To the determination of the efficiency of heat exchange surfaces in conditions of convective heat transfer, Power engineering and transport, 3 (1990) 168-171.

[10] V.M. Case, A.L. London, Compact heat exchangers, Moscow, Energy, (1967).

[11] E.K. Kalinin, G.A. Draycer, C.A. Yarho, Intensification of heat exchange in channels. Moscow, Mechanical engineering, (1972).

[12] V.A. Kirpikov, V.K. Orlov, V.F. Prihodko, Creating compact surface of heat exchange based on the idea of inflowing pressure inhomogeneities, Thermal power engineering, 4 (1977) 32-33.

[13] V.M. Antufiev, Efficiency in forms of convective heating surfaces, Moscow, Energy, (1966).
