The Effect of the Operating Speed and Wheel Characteristics on the Surface Quality at Creep-Feed Grinding Titanium Alloys

Abstract:

The paper dwells upon flat creep-feed grinding of grooves in Ti6Al4V workpieces. Those were machined with high-porosity silicon carbide wheels of I, H grades at a speed of 20-30 m/s. Machined surfaces were analyzed using a Versa 3D electron microscope. The paper demonstrates the formed morphology of ground surfaces along the workpiece. Higher-speed grinding results in greater concentrations of silicon on the machined titanium alloy surface. Altering the characteristics of the abrasive tool does not have a significant effect on the concentration of silicon on machined surfaces. The paper analyzes how the grade of wheel and the grinding speed affect Ra surface roughness parameter. The article demonstrates the difference in grades of wheels along the surface, at the stage of constant length of arc and the stage of exit.

• Periodical: Solid State Phenomena (Volume 284)
• Pages: 369-374
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.284.369
• Online since: October 2018
• Authors: S.V. Nosenko, V.A. Nosenko*, A.A. Koryazhkin
• Keywords: Chemical Composition, Creep-Feed Grinding, Grade of Wheel, Morphology, Operating Speed, Surface Roughness, Titanium Alloys

References

[1] V.K. Starkov, Highly porous grinding wheels, Mashinostroenie, Moscow, (2007).

[2] V.A. Poletaev, D.I. Volkov, Deep grinding of turbine blades, Mashinostroenie, Moscow, (2009).

[3] V.A. Nosenko, S.V. Nosenko, The technology of grinding the metals, TNT, Stary Oskol, (2013).

[4] V.A. Nosenko, Interaction intensity criterion for machined and abrasive material in grinding, Journal of Machinery Manufacture and Reliability. 5 (2001) 85–91.

[5] Xu Xipeng, Yu Yiqing, Mechanisms of abrasive wear in the grinding of titanium (TC4) and nickel (K417) alloys, Wear. 7 (2003) 1421–1426.

DOI: 10.1016/s0043-1648(03)00163-7

[6] D.T. Curtis, S.L. Soo, D.K. Aspinwall, A.L. Mantle, Evaluation of workpiece surface integrity following point grinding of advanced titanium and nickel based alloys, Procedia CIRP. 45 (2016) 47–50.

DOI: 10.1016/j.procir.2016.02.343

[7] S.V. Nosenko, V.A. Nosenko, A.A. Krutikova, L.L. Kremenetskii, Surface-layer composition of titanium alloy after dry grinding by a silicon-carbide wheel, Russian Engineering Research. 7 (2015) 554–557.

DOI: 10.3103/s1068798x15070163

[8] K. Nadolny, A review on single-pass grinding processes, Journal of Central South University. 6 (2013) 1502–1509.

DOI: 10.1007/s11771-013-1641-5

[9] V.A. Nosenko, S.V. Nosenko, Deep grinding of titanium alloy with continuous wheel correction, Russian Engineering Research. 11 (2010) 1124–1128.

DOI: 10.3103/s1068798x10110110

[10] Sein Leung Soo, R. Hood, M. Lannette, D.K. Aspinwall, W. Voice, Creep feed grinding of burn-resistant titanium (BuRTi) using superabrasive wheels, International Journal of Advanced Manufacturing Technology. 9 (2011) 1019–1026.

DOI: 10.1007/s00170-010-2876-z

[11] V.A. Nosenko, S.V. Nosenko, Flat deep groove grinding in titanium alloy block with continuous dressing grinding wheel, Vestnik Mashinostroeniya. 4 (2013) 74–79.

DOI: 10.3103/s1068798x10110110

[12] S.V. Nosenko, V.A. Nosenko, L.L. Kremenetskii, Influence of dressing of the wheel on the surface quality of titanium alloy in deep grinding, Russian Engineering Research. 10 (2014) 632–636.

DOI: 10.3103/s1068798x14100128

[13] V.A. Nosenko, N.F. Larionov, N.I. Egorov, M.P. Volkov, The selection characteristics of the abrasive tool and the coolant for deep grinding, Soviet Engineering Research. 5 (1989) 17–21.

[14] V.A. Nosenko, Improvement of abrasive tools on bakelite base, Journal of Machinery Manufacture and Reliability. 3 (2004) 85–90.

[15] R. Hood, F. Lechner, D.K. Aspinwall, W. Voice, Creep feed grinding of gamma titanium aluminide and burn resistant titanium alloys using SiC abrasive, International Journal of Machine Tools and Manufacture. 9 (2007) 1486–1492.

DOI: 10.1016/j.ijmachtools.2006.10.008

[16] V.A. Nosenko, V.K. Zhukov, A.A. Vasil'ev, S.V. Nosenko, Deep grinding of incomplete-cycle surfaces with periodic straightening of the wheel, Russian Engineering Research. 5 (2008) 442–449.

DOI: 10.3103/s1068798x08050109

[17] V.A. Nosenko, Unidirectional and opposing deep grinding of titanium alloy with periodic wheel adjustment, Russian Engineering Research. 10 (2010) 1016–1021.

DOI: 10.3103/s1068798x10100114

[18] S.V. Nosenko, V.A. Nosenko, A.A. Bairamov, Factors affecting the surface roughness in the deep grinding of titanium alloys, Russian Engineering Research. 7 (2015) 549–553.

DOI: 10.3103/s1068798x15070151

[19] V.A. Nosenko, S.V. Nosenko, Mathematical models of operating time and cutting capacity for various stages of flat creep feed grinding of horizontal surface by circle of direct profile, Journal of Machinery Manufacture and Reliability. 4 (2010).

DOI: 10.3103/s1052618810040138

[20] S.V. Nosenko, V.A. Nosenko, L.L. Kremenetskii, The condition of machined surface of titanium alloy in dry grinding, Procedia Engineering. 206 (2017) 115–120.

DOI: 10.1016/j.proeng.2017.10.446
