New Composite Construction Method with STEEL/UHPFRC Constructing Railway Bridges

Abstract:

In Austria last years sequenced according modern technology successfully bridges were made from UHPC or UHPFRC [1], [2], [3]. A couple of well-done examples of these bridges I presented on the occasion of Prof. Sparowitz birthday publication in 2017 [2]. Recently in Austria another example of a railway bridge consisting innovative material UHPFRC - created as a composite construction - was projected by ZKP ZT GmbH by order of Austrian Railway Company ÖBB. Innovative and new is the application of Ultra-High Performance Concrete in combination with Steel S355J2+N creating a composite action in highest utilization of both material strengths and auxiliary connected with a steel panel. Construction work was done from March to September 2017, the bridge was finished in October 2017 in single railway track Lavanttalbahn near city Wolfsberg in Carinthia.

• Periodical: Solid State Phenomena (Volume 292)
• Pages: 242-248
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.292.242
• Online since: June 2019
• Authors: Welf Zimmermann*, Stefan Kuss
• Keywords: Auenbach Bridge, Composite Structure STEEL/UHPFRC, UHPFRC, Ultra-High Performance Concrete (UHPC)

References

[1] Sparowitz L., Reichel M., Freytag B.; (2008): Anwendung von faserbewehrtem ultra Hochleistungsbeton im Brückenbau. Fachtagung der Österreichischen Vereinigung für Beton- und Bautechnik, Wien.

[2] Zimmermann W., (2015): Brücken in Österreich aus ultrahochfestem Beton (UHPC und UHPFRC), Beitrag zum Festkolloquium anlässlich des 75. Geburtstages von Prof. Sparowitz an der TU Graz.

[3] Reichel M., Freytag B., Sparowitz L., Zimmermann W. (2009): Road Bridge WILD - UHPFRC for a segmental arch structure. Vortrag zur Fachtagung der FIB und AFCG.

DOI: 10.1002/9781118557839.ch14

[4] Association Française de Genie Civil (AFGC); (2002): Documents scientifiques et techniques Bétons fibrés à ultra-hautes performances,, Recommandations provisoires.

[5] König,G.; Nguyen V.T.; Zink M. (2001): Hochleistungsbeton, Bemessung, Herstellung und Anwendung, Ernst & Sohn.

[6] Deutscher Ausschuss für Stahlbetonbau DAfStb, (2008): Heft 561, Sachstandsbericht Ultrahochfester Beton,, Beuth Verlag GmbH, Berlin, Wien, Zürich.

[7] Freytag B., Sliscovic V., Linder J., Fülöp U. (2017): Auenbachbrücke Prüfbericht, Nr. F-10-58-(2017).

[8] Eurocodes EN 1992, EN 1993, EN 1994 including all Standards.
