The Influence of Cylindrical Specimen Size and Material Properties on the Distribution of Deformation during Torsion Test

Abstract:

Torsion tests allow to study the rheological properties of various materials, including properties in hot state, as well as they allow to conduct physical simulations of real material forming processes, including processes of intensive and alternating deformation. However, it is often a question what size the specimen should have to perform torsion test accurately. The article aims to study the influence of cylindrical specimen size on the distribution of deformation during torsion test. For this purpose, computer simulation of the torsion testing process was performed. The influence of the relative length of the specimen gauge on the deviation of the actual values of the effective strain from the calculated values was quantified. It is shown that the error in the calculation of the effective strain, based on the values of the twist angle and the specimen gauge size, is of 4%. In order to verify the results obtained by computer simulation, the physical simulation was performed. It is shown that the distribution of deformation along the length of the specimen gauge is also significantly influenced by the accuracy of specimen manufacture, as well as the specimen material. In some cases, the error in the calculation of the effective strain, based on the values of the twist angle and the specimen gauge size, can reach more than 80%.

• Periodical: Solid State Phenomena (Volume 299)
• Pages: 323-329
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.299.323
• Online since: January 2020
• Authors: Mikhail Erpalov*
• Keywords: Finite Element Simulation, Physical Simulation, Shear Strain, Specimen Sizes, Strain Effective, Torsion Test

References

[1] D. Barraclough, H. Whittaker, K. Nair, Effect of Specimen Geometry on Hot Torsion Test Results for Solid and Tubular Specimens, Journal of Testing and Evaluation. 3-1 (1973) 220-226.

DOI: 10.1520/jte10007j

[2] A. Johansen, B. Ronning, N. Ryum, Comparison of solid and tubular specimens in hot torsion testing of an aluminum alloy, Aluminum Alloys, Proceedings of ICAA-6. 1 (1988) 559-594.

[3] H.-Ch. Wu, Zh. X., Paul, T. Wang, Torsion test of aluminium in the large strain range, International Journal of Plasticity. 13 (1997) 873-892.

DOI: 10.1016/s0749-6419(97)00064-8

[4] Mr. Rajkumar, D. Patil1, P.N. Gore, Review the Effect of Specimen Geometry on Torsion Test Results, International Journal of Innovative Research in Science, Engineering and Technology. 12-(2013) 7567-7574.

[5] Sh. Khoddam, Y.C. Lam and P.F. Thomson, The effect of the geometry of hot torsion test specimens on the accuracy of the constitutive equation, Steel Research. 2-66 (1995) 45-49.

DOI: 10.1002/srin.199501086

[6] A. Graber, K. Pohlandt, State of the art of the torsion test for determining flow curves, Steel Research. 5-61 (1990) 212-218.

DOI: 10.1002/srin.199000334

[7] Sh. Khoddam, Y.C. Lam, P.F. Thomson, A method of finding the effective length of the specimen used in the hot torsion test and recommendations on geometry of the test specimen, Journal of Testing and Evaluation. 2-26 (1998) 157–167.

DOI: 10.1520/jte11987j

[8] Sh. Khoddam, Variations of effective length of the hot torsion test specimen with deformation, Journal of Materials Processing Technology. 177 (2006) 465–468.

DOI: 10.1016/j.jmatprotec.2006.03.215

[9] B. Mirzakhani, H. Arabi, M. T. Salehi, S. H. Seyedein, M. R. Aboutalebi, Sh. Khoddam and A. Mohammadi, Computer aided optimization of specimen geometry of hot torsion test to minimize microstructure non homogeneity and temperature gradient before deformation, Iranian Journal of Materials Science & Engineering. 3-6 (2009) 35-43.

DOI: 10.1016/s1006-706x(10)60069-6

[10] B. Mirzakhani, Sh. Khoddam, H. Arabi, M.T. Salehi, J. Sietsma, A coupled Thermal-mechanical FE Model of Flow Localization during the Hot Torsion Test, Steel Research International. 11 (2009) 846-584.

[11] B. Mirzakhani, Sh. Khoddam, H. Arabi [at all], Influence of Specimen Geometry of Hot Torsion Test on Temperature Distribution During Reheating Treatment of API-X70, Journal of iron and steel research international. 17-3 (2010) 34-39.

DOI: 10.1016/s1006-706x(10)60069-6

[12] J.J. Jonas, C. Ghosh, L.S. Toth. The equivalent strain in high pressure torsion, Materials Science & Engineering. 607 (2014) 530-535.

DOI: 10.1016/j.msea.2014.04.046

[13] V.L. Kolmogorov, Mekhanika obrabotki metallov davleniem, UPI, Sverdlovsk, (1981).

[14] S. Onaka, A comparison of the von Mises and Hencky equivalent strains for use in simple shear experiments, Philosophical Magazine. 18-92 (2012) 2264-2271.

DOI: 10.1080/14786435.2012.671551

[15] M.V. Erpalov, Examination of Hardening Curves Definition Methods in Torsion Test, Solid State Phenomena. 284 (2018) 598-604.

DOI: 10.4028/www.scientific.net/ssp.284.598

[16] D.A. Pavlov, M.V. Erpalov, Investigation of the influence of material properties on the inhomogeneity of deformation during lengthwise rolling of tubes on a stub mandrel, 10-1 (2018) 17-21.

DOI: 10.1016/j.matpr.2019.07.053
