Improvement of Methods of Calculation of Forces in Hot Strip Rolling

Abstract:

A new solution Karman’s equation with the Mises plasticity condition is proposed for determining contact stresses in the slip zones for hot strip rolling. Replacement of the precise plasticity condition by an approximate condition in terms of primary stress leads to a substantial decrease in the length of slip zones and to increase of the rolling force. It was shown that, even at high frictional coefficients, the length of slip zones forms a significant part of the length of deformation region. On the basis of the obtained solutions the techniques for plotting curves of the normal contact stresses, determining the length of the slip zones, the neutral position of the cross section and rolling force refined.

• Periodical: Solid State Phenomena (Volume 299)
• Pages: 577-581
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.299.577
• Online since: January 2020
• Authors: Georgy L. Baranov*
• Keywords: Contact Stress, Hot Strip Rolling, Karman’s Equation, Length of Slip Zones, Neutral Cross Section, Rolling Force

References

[1] A.I. Celikov, G.S. Nikitin, S.E. Rokotyan, Teoriya prodolnoj prokatki, Metallurgiya, Moscow, (1980).

[2] A.A. Korolev, Konstrukciya i raschet mashin i mekhanizmov prokatnyh stanov, Metallurgiya, Moscow, (1985).

[3] A.P. Smiryagin, N.Z. Dnestrovskij, A.D. Landihov i dr., Obrabotka cvetnyh metallov i splavov, Spravochnik, Metallurgizdat, Moscow, (1961).

[4] N.N. Malinin, Tekhnologicheskie zadachi plastichnosti i polzuchesti, Vysshaya shkola, Moscow, (1979).

[5] V.S. Smirnov, Teoriya obrabotki metallov davleniem, Metallurgiya, Moscow, (1973).

[6] E.P. Unksov, Inzhenernaya teoriya plastichnosti, Mashgiz, Moscow, (1959).

[7] D.R. Bland, H. Ford, The calculation of roll force and torque in cold strip rolling with tension, Proceedings of the Institution of Mechanical Engineers, 1(159) (1948) 144-163.

DOI: 10.1243/pime_proc_1948_159_015_02

[8] R.B. Sims, Calculation of roll force and torque in hot rolling mills, Proceedings of the Institution of Mechanical Engineers, 6(68) (1954) 191-200.

DOI: 10.1243/pime_proc_1954_168_023_02

[9] R. Pernis, The new hypothesis of normal stress distribution for contact arc in rolling, Acta Metallurgica Slovaca, 2(17) (2011) 68-76.

[10] A. Nadai Plastichnost i razrushenie tverdyh tel, Inostrannaya literatura, Moscow,(1954).

[11] V.V. Sokolovskij, Teoriya plastichnosti, Vysshaya shkola, Moscow, (1969).

[12] E.P. Unksov, U.Dzhonson, V.L. Kolmogorov i dr., Teoriya plasticheskih deformacij metallov, Mashinostroenie, Moscow, (1983).

[13] G.L. Baranov, Napryazhennoe sostoyanie pri plasticheskom techenii materiala v klinovidnom skhodyashchemsya kanale, Izv. vuzov. Mashinostroenie, Moscow, 1 (1984) 7-11.

[14] G.L. Baranov, Opredelenie kontaktnyh napryazhenij pri osadke pryamougolnoj polosy, Izv. vuzov. Cvetnaya metallurgiya, Moscow, 4 (2015) 25-31.

[15] G.L. Baranov, Kontaktnye napryazheniya pri plasticheskom techenii metalla v klinovidnom kanale, Izv. vuzov. Chernaya metallurgiya, Moscow, 6(58) (2015) 429-433.

[16] G.L. Baranov, Analiz kontaktnyh napryazhenij v zone ochaga plasticheskoj deformacii so znakoperemennymi silami treniya, Izv. vuzov. Chernaya metallurgiya, 3(58) (2015) 192-195.

[17] G.L. Baranov, Improved Calculation of the Contact Stress in Strip Rolling, Steel in translation, 6(45) (2015) 447-452.

DOI: 10.3103/s0967091215060042

[18] G.L. Baranov, Improvement of methods for calculating technological loads in metal forming processes, AIP Conference Proceedings 1785, 040005 (2016).

DOI: 10.1063/1.4967062

[19] A.P. Grudev, Teoriya prokatki, Internet Inzhiniring, Moscow, (2001).

[20] A.P. Grudev, Trenie i smazki pri obrabotke metallov davleniem. Spravochnik, Metallurgiya, Moscow, (1982).

[21] I.YA. Tarnovskij, A.N. Levanov, M.I. Poksevatkin, Kontaktnye napryazheniya pri plasticheskoj deformaci, Metallurgiya, Moscow, (1966).
