Numerical Quantification of Structure-Property Relations in DP800 - Influence of Phase Material Models in RVE

Abstract:

Understanding the relationships between microstructure and (mechanical) properties is inevitable for the design of modern structural metallic materials. A crucial property for most high-strength steels is ductile damage tolerance, since ductile damage can accumulate during cold forming, which either leads to failure in the forming process or subsequently affects the performance. Structure-property relations are often investigated using numerical methods, e.g. crystal plasticity (CP) modeling with representative volume elements (RVE). In a previous study, CP-simulations on 3D-RVE were coupled with surrogate modeling techniques performing a variance-based sensitivity analysis. This analysis enables quantitative descriptions of the relationships between microstructure features with the damage tolerance, quantified by individual indicators for individual damage mechanisms. To investigate the effect of the material model and the corresponding phase properties, 500 sRVE simulations were carried out with different CPparameter sets and the damage tolerance is investigated. All sets stem from the same DP800 but were calibrated with different approaches. Surrogate models were trained on the simulative database to calculate Sobol Indices (SI), which are a measure of how strong damage tolerance is affected by a particular microstructure feature. The SI are compared for the individual material models and damage indicators. The structure-property quantification is heavily influenced by the different material models, resulting in different values for the SI and a different order for the individual microstructure features. The main factor for the pronounced differences is the differently evolving mechanical phase contrast between ferrite and martensite.

• Periodical: Solid State Phenomena (Volume 390)
• Pages: 19-29
• DOI: https://doi.org/10.4028/p-MDl8Q0
• Online since: April 2026
• Authors: Niklas C. Fehlemann*, Sebastian Münstermann
• Keywords: Crystal Plasticity, Damage, Dual Phase Steel, Microstructure, Representative Volume Element, Sensitivity Analysis
