Leakage Power Reduction in 32-bit Digital Comparator Using Modified Power Gating Technique

Abstract:

As scaling down of CMOS transistor’s channel length is done for miniaturization, the design community primarily focuses on the high performance & power-aware design. The power consumption of any circuit solely holds the performance and the life of it. But static power consumption deteriorates them and dominates the dynamic power consumption because of its leakage components. A modified approach of pulse triggering in the Power Gating technique called MPG (Modified Power Gating) is proposed to reduce the static power consumption (leakage power) of digital subsystems. Sub threshold leakage power of MPG Inverter (INV) and 32-bit Digital Comparator (DC) is analyzed and reduced with 35% to 40% leakage savings compared with conventional and existing techniques by simulating it in Cadence GPDK.

• Periodical: Applied Mechanics and Materials (Volume 742)
• Pages: 741-744
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.742.741
• Online since: March 2015
• Authors: G. Amuthavalli*, R. Gunasundari, A. Nijandan
• Keywords: 32-bit Digital Comparator, Cadence, Circuit-Level, Power Gating, Short Pulse, Static Power, Sub Threshold Leakage Power

References

[1] Kaushik Roy, Saibal Mukhopadhyay and Hamid Mahmoodi-Meimand: Leakage Current Mechanisms and Leakage Reduction Techniques in Deep-Submicrometer CMOS Circuits, Proceedings of the IEEE, Vol. 91, No. 2, February (2003).

DOI: 10.1109/jproc.2002.808156

[2] Nam Sung KimTodd Austin David Blaauw Trevor Mudge, Krisztián Flautner, Jie S. Hu Mary Jane Irwin Mahmut Kandemir and Vijaykrishnan Narayanan: Leakage Current: Moore's Law Meets Static Power, Published by the IEEE Computer Society, (2003).

DOI: 10.1109/mc.2003.1250885

[3] Ramesh Vaddi, S. Dasgupta, and R. P. Agarwal: Device and Circuit Design Challenges in the Digital Subthreshold Region for Ultralow-Power Applications, Hindawi Publishing Corporation, VLSI Design, Volume (2009).

DOI: 10.1155/2009/283702

[4] Bernhard Goll and Horst Zimmermann: A Comparator with Reduced Delay Time in 65-nm CMOS for Supply Voltages down to 0. 65 V, IEEE Transactions on Circuits and Systems-Ii: Express Briefs, Vol. 56, No. 11, November (2009).

DOI: 10.1109/tcsii.2009.2030357

[5] Eitan N. Shauly: CMOS Leakage and Power Reduction in Transistors and Circuits: Process and Layout Considerations, J. Low Power Electron. Appl. 2012, 2, 1-29.

DOI: 10.3390/jlpea2010001

[6] Saleh Abdel-Hafeez, Ann Gordon-Ross and Behrooz Parhami: Scalable Digital CMOS Comparator using a Parallel Prefix Tree, IEEE Transactions on Very Large Scale Integration (VLSI) Systems, Vol. 21, No. 11, November (2013).

DOI: 10.1109/tvlsi.2012.2222453

[7] Christophe J. Merlin and Wendi B. Heinzelman: Duty Cycle Control for Low-Power-Listening MAC Protocols, IEEE Transactions on Mobile Computing, Vol. 9, Issue. 11, July (2010).

DOI: 10.1109/tmc.2010.116

[8] Linet. K: Modified 4-Bit Comparator using Sleep Technique, International Journal of Computer Science & Engineering Technology (IJCSET), Vol. 5 No. 05 May (2014).

[9] Bhaskara Rao Doddi, B.N. Srinivasa Rao and R. Prasad Rao: A Low Power 8-bit Magnitude Comparator with Small Transistor Count using STATIC CMOS Logic, International Journal of Advanced Research in Computer Engineering & Technology Vol. 2, Issue 11, Nov (2013).

[10] Geetanjali Sharma, Uma Nirmal and Yogesh Misra: A Low Power 8-bit Magnitude Comparator with Small Transistor Count using Hybrid PTL/CMOS Logic, International Journal of Computer Engineering & Management, Vol. 12, April (2011).

[11] Vijaya Shekhawat, Tripti Sharma and K. G. Sharma: Low Power Magnitude Comparator Circuit Design, International Journal of Computer Applications, Vol. 94 – No 1, May (2014).

DOI: 10.5120/16308-5535

[12] Anjuli and Sathyajith Anand: 2-bit Magnitude Comparator Design using Different Logic Styles, International Journal of Engineering Science Invention, Vol. 2 Issue 1 Jan (2013).

[13] Information on http: /www. itrs. net/papers. html.
